ĐẠI LÝ BECKHOFF VIỆT NAM | NHÀ PHÂN PHỐI BECKHOFF TẠI VIỆT NAM
- MÃ SẢN PHẨM:BECKHOFF VIỆT NAMCÔNG TY TNHH THƯƠNG MẠI VÀ DỊCH VỤ TĂNG MINH PHÁT là đại lý BECKHOFF tại VIỆT NAM
-
- Thông Tin Sản Phẩm
- Đánh Giá
Đại Diện hãng Beckhoff Tại Việt Nam
Lời đầu tiên, Công ty TNHH TM DV Tăng Minh Phát (TMP) xin gửi lời cảm ơn chân thành đến quý khách hàng đã, đang và sẽ sử dụng dịch vụ của chúng tôi. Kính chúc Quý Khách sức khỏe, hạnh phúc và
thịnh vượng.
Chúng tôi đang là nhà phân phối và thực hiện dịch vụ thiết bị Tự Động Hóa như : Cảm biến, Biến Tần, PLC, HMI, Motor, Motor Servo, Relays……, của nhiều hãng lớn đến từ các nước như: Đức, Mỹ, Nhật, Ý, Hàn Quốc, Pháp.... Đảm bảo uy tín , chất lượng , giá cả cạnh tranh, hợp tác lâu dài, giúp giảm các chi phí , giải quyết các nhu cầu cho khách hàng.
CÁC SẢN PHẨM :
1. Industrial PC | Máy tính công nghiệp Beckhoff
a. Panel PCs | Màn hình Beckhoff
Built-in Panel PCs
- CP22xx Multi-touch built-in Panel PC : Industrial PC with multi-finger touch screen, 3½-inch mother- board with one Mini PCI slot
- CP26xx Dual-touch built-in Panel PC : Industrial PC with dual-finger touch screen, 3½-inch mother- board
-
CP27xx Fanless multi-touch built-in Panel PC : Industrial PC with multi-finger touch screen, 3½-inch mother-board
Panel PCs IP 65
- CP32xx Multi-touch Panel PC : Industrial PC with multi-finger touch screen, 3½-inch mother-board with one Mini PCI slot
- CP37xx Multi-touch Panel PC : Industrial PC with multi-finger touch screen, 3½-inch mother-board
-
CP37xx-1600 Beckhoff | Máy tính công nghiệp IPC Beckhoff
b. Control cabinet PCs | Tủ điều khiển Beckhoff
19-inch slide-in Industrial PC ( Máy tính công nghiệp 19 in)
- C51xx : 19-inch slide-in Industrial PC : ATX motherboard or slot motherboard on passive backplane Model : C5102-0070, C5102-0060, C5102-0050, C5240-0010, C5240-0000
- C5210 : 19-inch slide-in Industrial PC : 3½-inch motherboard with on-board RAID controller Model : C5210-0030, C5210-0020, C5210-0010
Control cabinet Industrial PCs
- C60xx : Ultra-compact Industrial PC with compact motherboard
- C61xx Control cabinet Industrial PC : ATX motherboard or slot motherboard on passive backplane in five housing sizes
- C62xx Control cabinet Industrial PC : ATX motherboard or slot motherboard on passive backplane in compact drawer housing
- C63xx Control cabinet Industrial PC : Slot motherboard on passive backplane in compact aluminium housing
- C65xx Control cabinet Industrial PC : Built-in PC with 3½-inch motherboard and external cooling fins
- C66xx Control cabinet Industrial PC : ATX motherboard in compact housing
- C67xx Control cabinet industrial server : Many-core Control
- C69xx Control cabinet Industrial PC : 3½-inch motherboard with one Mini PCI slot in compact aluminium housing
- CP72xx Beckhoff | Máy tính công nghiệp IPC Beckhoff
- CP77xx Beckhoff | Máy tính công nghiệp IPC Beckhoff
c. Control Panel
- CP29xx : Multi-touch built-in Control Panel with DVI/USB Extended interface. The PC operating terminal for installation in the control cabinet door
- CP39xx : Multi-touch Control Panel with DVI/USB Extended interface. The PC operating terminal for mounting arm installation
- CP79xx : Control Panel with DVI/USB interface
- CP79xx : Stainless steel Control Panel with DVI/USB interface
d. Embedded PC
Modular DIN rail Industrial PCs
With the Embedded PCs of the CX series, Beckhoff has combined PC technology and modular I/O level on a DIN rail unit in the control cabinet. The CX device series combines the worlds of Industrial PC and hardware PLC and is suitable for all performance control tasks. The modular system of the CX series can be configured to match the task in hand: by adding or omitting units and interfaces, only those components that the system actually requires are installed on the DIN rail in the control cabinet or terminal box. Installation space and costs are reduced.
Devices with x86 CPU:
- CX2072: many-core CX with Intel® Xeon® D-1567 2.1 GHz, 12 cores
- CX2062: many-core CX with Intel® Xeon® D-1548 2.0 GHz, 8 cores
- CX2042: many-core CX with Intel® Xeon® D-1527 2.2 GHz, 4 cores
- CX2040: multi-core CX with Intel® Core™ i7 CPU, 2.1 GHz, 4 cores
- CX2030: multi-core CX with Intel® Core™ i7 CPU, 1.5 GHz, 2 cores
- CX2020: high-performance CX with Intel® Celeron® CPU, 1.4 GHz
- CX5240: multi-core CX with Intel® Atom™ CPU, 1.6 GHz, 4 cores
- CX5230: multi-core CX with Intel® Atom™ CPU, 1.3 GHz, 2 cores
- CX5140: multi-core CX with Intel® Atom™ CPU, 1.91 GHz, 4 cores
- CX5130: multi-core CX with Intel® Atom™ CPU, 1.75 GHz, 2 cores
- CX5120: compact CX with Intel® Atom™ CPU, 1.46 GHz
- CX5020: compact CX with Intel® Atom™ CPU, 1.6 GHz
- CX5010: compact CX with Intel® Atom™ CPU, 1.1 GHz
- CX1030: high-performance CX with Intel® Pentium® M CPU, 1.8 GHz
- CX1020: high-performance CX with Intel® Celeron® M ULV CPU, 1 GHz
- CX1010: basic CX with Pentium® MMX-compatible CPU, 500 MHz
Devices with ARM CPU:
- CX9020: Ethernet controller with ARM Cortex™-A8 CPU, 1 GHz
- CX8100: basic CX with ARM Cortex™-A9 CPU, 800 MHz, and integrated fieldbus interface
- CX8000: basic CX with ARM9 CPU, 400 MHz, and integrated fieldbus interface
- CX7000: basic CX with ARM Cortex™-M7, 400 MHz, and integrated fieldbus interface
Control cabinet PCs
- C6015 | Control cabinet IPC
- C6017 | Control cabinet IPC
- C6030 | Control cabinet IP
- C6032 | Control cabinet IPC
- C6140 | Control cabinet IPC
- C6150 | Control cabinet IPC
- C6240 | Control cabinet IPC
- C6250 | Control cabinet IPC
- C6320 | Control cabinet IPC
e. Motherboards | Bo mạch chủ Beckhoff
Motherboards with Intel® x86 and ARM architecture
Beckhoff has expanded the “Industrial Motherboards” line of business into an independent product segment, with in-house board development, design and production. Beckhoff can thus offer Industrial PCs and Embedded PCs in all performance classes with motherboards developed in-house.
Một số model Industrial PC Beckhoff thường dùng
Product | Description |
CP22xx-0010 | Multi-touch built-in Panel PC CP22xx-0010, Multi-finger touch screen |
C9900-M575 | vertical orientation of the display inside the Control Panel or Panel PC CP22xx, CP26xx, CP29xx or CP39xx instead of standard Control Panel or standard Panel PC |
C9900-E268 | 1-port USB socket inside the front of a CP2xxx without push-button extension, USB-A socket IP 65 |
C9900-C562 | processor 4th Generation Intel® Core™ i3 4100E, 2.4 GHz, 2 cores (TC3: 60), instead of Intel® Celeron® 2000E 2.2 GHz (TC3: 50) |
C9900-C570 | processor 4th Generation Intel® Core™ i3 4110E, 2.6 GHz, 2 cores (TC3: 60), instead of Intel® Celeron® 2000E 2.2 GHz (TC3: 50) |
C9900-C563 | processor 4th Generation Intel® Core™ i5 4400E, 2.7 GHz, 2 cores (TC3: 70), instead of Intel® Celeron® 2000E 2.2 GHz (TC3: 50) |
C9900-C571 | processor 4th Generation Intel® Core™ i5 4410E, 2.9 GHz, 2 cores (TC3: 70), instead of Intel® Celeron® 2000E 2.2 GHz (TC3: 50) |
C9900-C564 | processor 4th Generation Intel® Core™ i7 4700EQ, 2.4 GHz, 4 cores (TC3: 80), instead of Intel® Celeron® 2000E 2.2 GHz (TC3: 50) |
C9900-R257 | memory extension to 4 GB DDR3L RAM, instead of 2 GB, requires a 64 bit operating system or only 3 GB are addressable |
C9900-R258 | memory extension to 8 GB DDR3L RAM, instead of 2 GB, requires a 64 bit operating system |
C9900-R259 | memory extension to 16 GB DDR3L RAM, instead of 2 GB, requires a 64 bit operating system |
C9900-B517 | 2 PCIe module slots integrated inside CP22xx, to plug-in Beckhoff PCIe modules, instead of 2 connector brackets to lead out interfaces |
C9900-E232 | sound line input and sound line output of the motherboard led out at the connection section of a C5210, C65x5, CP22xx or CP62xx |
C9900-E233 | 1 serial port RS232 of the motherboard led out at the connection section of a C5210, C65x5, CP2xxx, CP62xx or CP67xx-xxxx-0040/-0050 |
C9900-E234 | 2 USB ports of the motherboard led out at the connection section of a C5210, C65x5, CP2xxx, CP62xx or CP67xx-xxxx-0040/-0050 |
C9900-E240 | Serial port COM2 RS232, optically linked, overload protection, D-sub 9-pin connector. |
C9900-E241 | Serial port COM2 RS485, optically linked, overload protection, D-sub 9-pin connector. Configuration as an end point without echo: echo off, auto send on, always send off, auto receive on, always receive off, termination on |
C9900-E242 | Serial port COM2 RS422, optically linked, overload protection, D-sub 9-pin connector. Configuration as a full duplex end point: echo on, auto send off, always send on, auto receive off, always receive on, termination on |
FC9071-0000 | Gigabit Ethernet PC interface card, 10/100/1000 Mbit/s, 1-channel, PCIe interface, occupies the connecting area of the Mini PCI card |
C9900-R230 | memory module NOVRAM for fail-safe storage of process data, 128 kB, Mini PCI plug-in card |
C9900-R231 | memory module NOVRAM for fail-safe storage of process data, 256 kB, Mini PCI plug-in card |
C9900-R232 | memory module NOVRAM for fail-safe storage of process data, 512 kB, Mini PCI plug-in card |
C9900-D191 | PC with 2 slots for 2½-inch hard disks or SSDs, instead of 1 slot for a hard disk or SSD and 1 slot for CFast |
C9900-H145 | additional hard disk, 2½-inch, 320 GB |
C9900-H741 | solid-state disk SSD, 3D flash, 2½-inch, 120 GB |
C9900-H749 | solid-state disk SSD, 3D flash, 2½-inch, 240 GB |
C9900-H745 | solid-state disk SSD, 3D flash, 2½-inch, 480 GB |
C9900-H742 | solid-state disk SSD, 3D flash, 2½-inch, 120 GB, instead of 2½-inch hard disk |
C9900-H750 | solid-state disk SSD, 3D flash, 2½-inch, 240 GB, instead of 2½-inch hard disk |
C9900-H746 | solid-state disk SSD, 3D flash, 2½-inch, 480 GB, instead of 2½-inch hard disk |
C9900-H700 | solid-state disk SSD, SLC flash, 2½-inch, 32 GB |
C9900-H705 | solid-state disk SSD, SLC flash, 2½-inch, 64 GB |
C9900-H735 | solid-state disk SSD, SLC flash, 2½-inch, 128 GB |
C9900-H701 | solid-state disk SSD, SLC flash, 2½-inch, 32 GB, instead of 2½-inch hard disk |
C9900-H706 | solid-state disk SSD, SLC flash, 2½-inch, 64 GB, instead of 2½-inch hard disk |
C9900-H736 | solid-state disk SSD, SLC flash, 2½-inch, 128 GB, instead of 2½-inch hard disk |
C9900-D190 | 2 slots for CFast cards, instead of 1 slot for a 2½-inch hard disk or SSD and 1 slot for CFast |
C9900-H583 | 30 GB CFast card, 3D flash, extended temperature range |
C9900-H587 | 60 GB CFast card, 3D flash, extended temperature range |
C9900-H550 | 4 GB CFast card, SLC flash, extended temperature range |
C9900-H551 | 8 GB CFast card, SLC flash, extended temperature range |
C9900-H552 | 16 GB CFast card, SLC flash, extended temperature range |
C9900-H563 | 32 GB CFast card, SLC flash, extended temperature range |
C9900-H568 | 64 GB CFast card, SLC flash, extended temperature range |
C9900-H584 | 30 GB CFast card, 3D flash, extended temperature range, instead of 2½-inch hard disk |
C9900-H588 | 60 GB CFast card, 3D flash, extended temperature range, instead of 2½-inch hard disk |
C9900-H553 | 4 GB CFast card, SLC flash, extended temperature range, instead of 2½-inch hard disk, less price |
C9900-H554 | 8 GB CFast card, SLC flash, extended temperature range, instead of 2½-inch hard disk, less price |
C9900-H555 | 16 GB CFast card, SLC flash, extended temperature range, instead of 2½-inch hard disk |
C9900-H565 | 32 GB CFast card, SLC flash, extended temperature range, instead of 2½-inch hard disk |
C9900-H569 | 64 GB CFast card, SLC flash, extended temperature range, instead of 2½-inch hard disk |
C9900-U209 | uninterruptible power supply UPS, integrated into the 24 V power supply, without battery, occupies one internal serial Interface |
C9900-U330 | battery pack for PCs with 24 V power supply and integrated UPS C9900-P209 or C9900-U209, external, for DIN rail mounting, 3.4 Ah, operating temperature 0…50 °C |
FC9062 | Gigabit Ethernet PCIe module for PCs with Beckhoff PCIe module slots, 2-channel, PCI Express x1 bus |
C9900-E277 | USB 3.0 PCIe module - 2-port USB 3.0 interfaces - USB transfer rate up to 5 Gbit/s for USB 3.0 - compatible to all USB standards - delivers up to 1 A supply current at each USB port |
CP2211-0010 | Multi-touch built-in Panel PC CP22xx-0010, 11.6-inch display 1366 x 768, Display only, Multi-finger touch screen |
CP2212-0010 | Multi-touch built-in Panel PC CP22xx-0010, 12-inch display 800 x 600, Display only, Multi-finger touch screen |
CP2215-0010 | Multi-touch built-in Panel PC CP22xx-0010, 15-inch display 1024 x 768, Display only, Multi-finger touch screen |
CP2216-0010 | Multi-touch built-in Panel PC CP22xx-0010, 15.6-inch display 1366 x 768, Display only, Multi-finger touch screen |
CP2218-0010 | Multi-touch built-in Panel PC CP22xx-0010, 18.5-inch display 1366 x 768, Display only, Multi-finger touch screen |
CP2219-0010 | Multi-touch built-in Panel PC CP22xx-0010, 19-inch display 1280 x 1024, Display only, Multi-finger touch screen |
CP2221-0010 | Multi-touch built-in Panel PC CP22xx-0010, 21.5-inch display 1920 x 1080, Display only, Multi-finger touch screen |
CP2224-0010 | Multi-touch built-in Panel PC CP22xx-0010, 24-inch display 1920 x 1080, Display only, Multi-finger touch screen |
CP22xx-0020 | Multi-touch built-in Panel PC CP22xx-0020, Multi-finger touch screen |
C9900-M575 | vertical orientation of the display inside the Control Panel or Panel PC CP22xx, CP26xx, CP29xx or CP39xx instead of standard Control Panel or standard Panel PC |
C9900-E268 | 1-port USB socket inside the front of a CP2xxx without push-button extension, USB-A socket IP 65 |
C9900-C607 | processor 6th Generation Intel® Pentium® G4400TE, 2.4 GHz, 2 cores (TC3: 50), instead of Intel® Celeron® G3900TE 2.3 GHz (TC3: 50) |
C9900-C608 | processor 6th Generation Intel® Core™ i3-6100TE, 2.7 GHz, 2 cores (TC3: 60), instead of Intel® Celeron® G3900TE 2.3 GHz (TC3: 50) |
C9900-C618 | processor 7th Generation Intel® Core™ i3-7101(T)E, 3.4 GHz, 2 cores (TC3: 60), requires Windows 10, 64 bit, instead of Intel® Celeron® G3900TE 2.3 GHz (TC3: 50) |
C9900-C609 | processor 6th Generation Intel® Core™ i5-6500TE, 2.3 GHz, 4 cores (TC3: 70), instead of Intel® Celeron® G3900TE 2.3 GHz (TC3: 50) |
C9900-C619 | processor 7th Generation Intel® Core™ i5-7500(T), 2.7 GHz, 4 cores (TC3: 70), requires Windows 10b 64 bit, instead of Intel® Celeron® G3900TE 2.3 GHz (TC3: 50) |
C9900-C610 | processor 6th Generation Intel® Core™ i7-6700TE, 2.4 GHz, 4 cores (TC3: 80), instead of Intel® Celeron® G3900TE 2.3 GHz (TC3: 50) |
C9900-C620 | processor 7th Generation Intel® Core™ i7-7700(T), 2.9 GHz, 4 cores (TC3: 80), requires Windows 10, 64 bit, instead of Intel® Celeron® G3900TE 2.3 GHz (TC3: 50) |
C9900-R270 | memory extension to 8 GB DDR4 RAM, instead of 4 GB, requires a 64 bit operating system |
C9900-R271 | memory extension to 16 GB DDR4 RAM, instead of 4 GB, requires a 64 bit operating system |
C9900-R272 | memory extension to 32 GB DDR4 RAM, instead of 4 GB, requires a 64 bit operating system |
C9900-B517 | 2 PCIe module slots integrated inside CP22xx, to plug-in Beckhoff PCIe modules, instead of 2 connector brackets to lead out interfaces |
FC9071-0000 | Gigabit Ethernet PC interface card, 10/100/1000 Mbit/s, 1-channel, PCIe interface, occupies the connecting area of the Mini PCI card |
C9900-D191 | PC with 2 slots for 2½-inch hard disks or SSDs, instead of 1 slot for a hard disk or SSD and 1 slot for CFast |
C9900-H145 | additional hard disk, 2½-inch, 320 GB |
C9900-H741 | solid-state disk SSD, 3D flash, 2½-inch, 120 GB |
C9900-H749 | solid-state disk SSD, 3D flash, 2½-inch, 240 GB |
C9900-H745 | solid-state disk SSD, 3D flash, 2½-inch, 480 GB |
C9900-H742 | solid-state disk SSD, 3D flash, 2½-inch, 120 GB, instead of 2½-inch hard disk |
C9900-H750 | solid-state disk SSD, 3D flash, 2½-inch, 240 GB, instead of 2½-inch hard disk |
C9900-H746 | solid-state disk SSD, 3D flash, 2½-inch, 480 GB, instead of 2½-inch hard disk |
C9900-H700 | solid-state disk SSD, SLC flash, 2½-inch, 32 GB |
C9900-H705 | solid-state disk SSD, SLC flash, 2½-inch, 64 GB |
C9900-H735 | solid-state disk SSD, SLC flash, 2½-inch, 128 GB |
C9900-H701 | solid-state disk SSD, SLC flash, 2½-inch, 32 GB, instead of 2½-inch hard disk |
C9900-H706 | solid-state disk SSD, SLC flash, 2½-inch, 64 GB, instead of 2½-inch hard disk |
C9900-H736 | solid-state disk SSD, SLC flash, 2½-inch, 128 GB, instead of 2½-inch hard disk |
C9900-D190 | 2 slots for CFast cards, instead of 1 slot for a 2½-inch hard disk or SSD and 1 slot for CFast |
C9900-H583 | 30 GB CFast card, 3D flash, extended temperature range |
C9900-H587 | 60 GB CFast card, 3D flash, extended temperature range |
C9900-H552 | 16 GB CFast card, SLC flash, extended temperature range |
C9900-H563 | 32 GB CFast card, SLC flash, extended temperature range |
C9900-H568 | 64 GB CFast card, SLC flash, extended temperature range |
C9900-H584 | 30 GB CFast card, 3D flash, extended temperature range, instead of 2½-inch hard disk |
2. Module I/O | Mô đun truyền thông Beckhoff
a. Bus Terminal | Thiết bị đầu cuối Beckhoff
- Bus Couplers: The Bus Couplers link the modularly expandable electronic terminal blocks with the respective fieldbus system. The Bus Coupler performs all the monitoring and control tasks that are necessary for operation of the connected Bus Terminals.
- Bus Terminal Controllers: The Bus Terminal Controllers are small controllers with a high degree of flexibility. They can be used as stand-alone control systems or as intelligent fieldbus slaves.
- Bus Terminals: The Bus Terminals enable the connection of all relevant sensors and actuators.
b. Chuẩn EtherCAT
- EtherCAT Terminals : The EtherCAT Terminal system is a modular I/O system consisting of electronic terminal blocks. The EtherCAT protocol remains fully intact down to the individual terminal.
EK1000 | EK1100 | EK1100-0008 | EK1101 | EK1101-0008 |
EK1101-0010 | EK1101-0080 | EKM1101 | EK1110 | EK1110-0043 |
EK1121-0010 | EK1122 | EK1122-0008 | EK1110-0008 | EK1122-0080 |
EK1300 | EK1310 | EK1322 | EK1400 | EK1501 |
EK1501-0010 | EK1501-0100 | EK1521 | EK1521-0010 | EK1541 |
EK1561 | EK1814 | EK1818 | EK1828 | EK1828-0010 |
EK1914 | EK1960 | BK1120 | BK1150 | BK1250 |
- EtherCAT Box: With the EtherCAT Box modules Beckhoff offers an EtherCAT I/O system in IP 67 protection. This way, the high performance of EtherCAT is available for harsh environments.
- EtherCAT plug-in modules: The modules from the EJ series reduce assembly and wiring costs and replace inflexible black box solutions in standard machines.
c. Chuẩn Fieldbus ( Chuẩn Fieldbus là gì ?)
Robust construction allows fieldbus modules to be fitted directly to machines. Control cabinets and terminal boxes are now no longer required
d. Chuẩn Lightbus ( Chuẩn Lightbus là gì ?)
Interface cards: An intelligent Lightbus interface board is integrated in the control computer.
Modules: The decentralised Lightbus modules (e.g. interface or input/output modules) are directly situated locally.
e. Infrastructure
Beckhoff rounds off its range of fieldbus components with the PCI-based PC Fieldbus Cards for Lightbus, PROFIBUS, CANopen, DeviceNet, SERCOS interface, Ethernet and the PCI Express v1.1 cards for PROFIBUS, CANopen and Ethernet. The cards were specifically developed for fast controllers and real-time tasks such as drive position control. To enable universal application, the interface cards are fitted with either one or two fieldbus channels. The Ethernet cards offer a maximum of four channels
### Module truyền thông Beckhoff
ET1100-0000-0001 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 10 pieces, packaging: loose |
ET1100-0000-0012 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 120 pieces, packaging: strip |
ET1100-0000-0024 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 240 pieces, packaging: strip |
ET1100-0000-0050 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 500 pieces, packaging: strip |
ET1100-0000-0100 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 1000 pieces, packaging: strip |
ET1100-0000-0250 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 2500 pieces, packaging: 1 reel |
ET1100-0000-0500 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 5000 pieces, packaging: 2 reels |
ET1100-0000-0750 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 7500 pieces, packaging: 3 reels |
ET1100-0000-1000 | EtherCAT ASICs, BGA128, 10 x 10 mm, price for 10000 pieces, packaging: 4 reels |
ET1200-0000-0001 | EtherCAT ASICs, QFN48, 7 x 7 mm, price for 10 pieces, packaging: loose |
ET1200-0000-0025 | EtherCAT ASICs, QFN48, 7 x 7 mm, price for 250 pieces, packaging: strip |
ET1200-0000-0075 | EtherCAT ASICs, QFN48, 7 x 7 mm, price for 750 pieces, packaging: strip |
ET1200-0000-0150 | EtherCAT ASICs, QFN48, 7 x 7 mm, price for 1500 pieces, packaging: strip |
ET1200-0000-0300 | EtherCAT ASICs, QFN48, 7 x 7 mm, price for 3000 pieces, packaging: 1 reel |
ET1200-0000-0600 | EtherCAT ASICs, QFN48, 7 x 7 mm, price for 6000 pieces, packaging: 2 reels |
ET1200-0000-0900 | EtherCAT ASICs, QFN48, 7 x 7 mm, price for 9000 pieces, packaging: 3 reels |
ET1810 | Node-locked license for using the EtherCAT IP core on one workstation. The license includes 1 year of maintenance and updates. |
ET1810-0010 | Extension of the node-locked Altera license (ET1810) for one additional workstation |
ET1810-0020 | One-year maintenance extension for node-locked license (ET1810) |
ET1812 | Floating buy out license for Altera FPGAs |
ET1812-0010 | Extension of the floating license (ET1812) for one additional workstation |
ET1812-0020 | One-year maintenance extension for floating license (ET1812) |
ET1815 | Node-locked license for using the EtherCAT IP core on one workstation. The license includes 1 year of maintenance and updates. |
ET1815-0010 | Extension of the node-locked Xilinx license (ET1815) for one additional workstation |
ET1815-0020 | One-year maintenance extension for node-locked license (ET1815) |
ET1811 | One-time kick-off charge for the node-locked quantity-based license for using the freely configurable EtherCAT IP cores on one workstation |
ET1811-1000 | Royalty for 1000 devices, ET1811 required |
ET1811-0020 | One-year maintenance extension, ET1811 required |
ET1811-0030 | System integrator OEM license |
ET1816 | One-time kick-off charge for the node-locked quantity-based license for using the freely configurable EtherCAT IP cores on one workstation; target hardware: selected Xilinx devices |
ET1816-1000 | Royalty for 1000 devices, ET1816 required |
ET1816-0020 | One-year maintenance extension, ET1816 required |
FB1311-0140 | EtherCAT P piggyback controller board with ET1100 and µC interface |
FB1311-0141 | EtherCAT P piggyback controller board with ET1100 and SP interface |
FB1311-0142 | EtherCAT P piggyback controller board with ET1100 and digital I/O interface |
FB1111-0140 | EtherCAT piggyback controller board with ET1100 and µC interface; can be integrated as EtherCAT interface in devices. |
FB1111-0141 | EtherCAT piggyback controller board with ET1100 and SPI interface; can be integrated as EtherCAT interface in devices. |
FB1111-0142 | EtherCAT piggyback controller board with ET1100 and digital I/O interface; can be integrated as EtherCAT interface in devices; included in the EL982x evaluation kit. |
ET2000 | Industrial Ethernet multi-channel probe |
ET9000 | License for using the EtherCAT configurator The license agreements for Beckhoff software products apply. |
ET9200 | License for using the EtherCAT Master Sample Code |
ET9300 | license for using the EtherCAT Slave Stack Code (free download from the member’s section of the EtherCAT Technology Group web page) |
ET9400 | 1-year license for using the EtherCAT Conformance Test Tool (user fee per year) |
ET9402 | Safety over EtherCAT Conformance Test Tool – includes a complete test set for testing the conformance of FSoE slave devices – The test set is approved by TÜV. – A valid subscription of the ET9400 is a prerequisite for the FSoE CTT. |
BK1120 | EtherCAT “Economy plus“ Bus Coupler for up to 64 Bus Terminals (255 with K-bus extension) |
BK1150 | EtherCAT “Compact“ Bus Coupler for up to 64 Bus Terminals (255 with K-bus extension) |
BK1250 | EtherCAT “Compact“ Coupler between EtherCAT Terminals (E-bus) and Bus Terminals (K-bus), adapter terminal |
EK1000 | EtherCAT TSN Coupler for networks with standard switch or with TSN-capable switch |
EK1100 | EtherCAT Coupler for E-bus terminals (ELxxxx) |
EK1100-0008 | EtherCAT Coupler for E-bus terminals (ELxxxx), with M8 screw-type connectors |
EK1101 | EtherCAT Coupler with ID switch for E-bus terminals (ELxxxx) |
EK1101-0080 | EtherCAT Coupler with ID switch for E-bus terminals (ELxxxx), Fast Hot Connect |
EK1122 | 2-port EtherCAT junction |
EK1122-0008 | 2-port EtherCAT junction, with M8 screw-type connectors |
EK1122-0080 | 2-port EtherCAT junction, Fast Hot Connect |
EK1501 | EtherCAT Coupler with ID switch, multimode fibre optic for E-bus terminals (ELxxxx) |
EK1501-0010 | EtherCAT Coupler with ID switch, singlemode fibre optic for E-bus terminals (ELxxxx), distance between stations up to 20 km |
EK1501-0100 | EtherCAT Coupler, media converter (multimode fibre optic to RJ45) with ID switch, for E-bus terminals (ELxxxx) |
EK1521 | 1-port EtherCAT multi-mode fibre optic junction |
EK1521-0010 | 1-port EtherCAT singlemode fibre optic junction, distance between stations up to 20 km |
EK1541 | EtherCAT Coupler with ID switch, plastic optical fibre for E-bus terminals (ELxxxx) |
EK1561 | 1-port EtherCAT plastic optical fibre junction |
EK1300 | EtherCAT P Coupler for E-bus terminals (ELxxxx) |
EK1322 | 2-port EtherCAT P junction |
EK1310 | EtherCAT P extension |
EK1110-0008 | EtherCAT extension, with M8 socket |
EK9160 | IoT Bus Coupler for EtherCAT Terminals (ELxxxx) |
EK1110 | EtherCAT extension |
EK1300 | EtherCAT P Coupler for E-bus terminals (ELxxxx) |
EK1310 | EtherCAT P extension |
EK1322 | 2-port EtherCAT P junction |
EK1814 | EtherCAT Coupler for E-bus terminals (ELxxxx) with integrated digital I/Os: – 4 digital inputs 24 V DC, filter 3.0 ms, type 3 – 4 digital outputs 24 V DC, 0.5 A, 1-wire system |
EK1818 | EtherCAT Coupler for E-bus terminals (ELxxxx) with integrated digital I/Os: – 8 digital inputs 24 V DC, filter 3.0 ms, type 3 – 4 digital outputs 24 V DC, 0.5 A, 1-wire system |
EK1828 | EtherCAT Coupler for E-bus terminals (ELxxxx) with integrated digital I/Os: – 4 digital inputs 24 V DC, filter 3.0 ms, type 3 – 8 digital outputs 24 V DC, 0.5 A, 1-wire system |
EK1828-0010 | EtherCAT Coupler for E-bus terminals (ELxxxx) with integrated digital I/Os: – 8 digital outputs 24 V DC, 0.5 A, 1-wire system |
EK1914 | EtherCAT Coupler for E-bus terminals (ELxxxx) with integrated digital standard and safety I/Os: – 6 digital inputs, 2 of which are fail-safe inputs, 24 V DC, filter 3.0 ms, type 3 – 6 digital outputs, 2 of which are fail-safe outputs, 24 V DC, 0.5 A, 1-wire system |
EK3100 | PROFIBUS Bus Coupler for EtherCAT Terminals (ELxxxx) |
EK9000 | Modbus TCP Bus Coupler for EtherCAT Terminals (ELxxxx) |
EK9300 | PROFINET RT Bus Coupler for EtherCAT Terminals (ELxxxx) |
EK9500 | EtherNet/IP Bus Coupler for EtherCAT Terminals (ELxxxx) |
EK9700 | SERCOS III Bus Coupler for EtherCAT Terminals (ELxxxx) |
EK1960-0000 | TwinSAFE Compact Controller for EtherCAT Terminals (ELxxxx) with integrated I/Os: – safe digital inputs 24 V DC – safe digital outputs 24 V DC, 2 A, 1-wire system safety protocol: TwinSAFE/Safety over EtherCAT connection: RJ45 |
EK1960-0008 | TwinSAFE Compact Controller for EtherCAT Terminals (ELxxxx) with integrated I/Os: – safe digital inputs 24 V DC – safe digital outputs 24 V DC, 2 A, 1-wire system safety protocol: TwinSAFE/Safety over EtherCAT connection: M8 |
EK1960-2600 | TwinSAFE Compact Controller for EtherCAT Terminals (ELxxxx) with integrated I/Os: – safe digital inputs 24 V DC – safe digital outputs 24 V DC, 2 A, 1-wire system – safe digital outputs, potential-free make contacts safety protocol: TwinSAFE/Safety over EtherCAT connection: RJ45 |
EK1960-2608 | TwinSAFE Compact Controller for EtherCAT Terminals (ELxxxx) with integrated I/Os: – safe digital inputs 24 V DC – safe digital outputs 24 V DC, 2 A, 1-wire system – safe digital outputs, potential-free make contacts safety protocol: TwinSAFE/Safety over EtherCAT connection: M8 |
EL1002 | 2-channel digital input terminal 24 V DC, filter 3.0 ms, 4-wire system |
ES1002 | 2-channel digital input terminal 24 V DC, filter 3.0 ms, 4-wire system |
EL1004 | 4-channel digital input terminal 24 V DC, filter 3.0 ms, 2-wire system |
ES1004 | 4-channel digital input terminal 24 V DC, filter 3.0 ms, 2-wire system |
EL1004-0020 | 4-channel digital input terminal 24 V DC, isolation voltage 2500 V, filter 3.0 ms, 2-wire system |
EL1008 | 8-channel digital input terminal 24 V DC, filter 3.0 ms, 1-wire system |
ES1008 | 8-channel digital input terminal 24 V DC, filter 3.0 ms, 1-wire system |
EL1012 | 2-channel digital input terminal 24 V DC, filter 10 µs, 3-wire system |
ES1012 | 2-channel digital input terminal 24 V DC, filter 10 µs, 3-wire system |
EL1014 | 4-channel digital input terminal 24 V DC, filter 10 µs, 2-wire system |
ES1014 | 4-channel digital input terminal 24 V DC, filter 10 µs, 2-wire system |
EL1018 | 8-channel digital input terminal 24 V DC, filter 10 µs, 1-wire system |
ES1018 | 8-channel digital input terminal 24 V DC, filter 10 µs, 1-wire system |
EL1024 | 4-channel digital input terminal 24 V DC for type 2 sensors, IEC 61131-2, filter 3.0 ms, 2-wire system |
ES1024 | 4-channel digital input terminal 24 V DC for type 2 sensors, IEC 61131-2, filter 3.0 ms, 2-wire system |
EL1034 | 4-channel digital input terminal 24 V DC for type 1 sensors, IEC 61131-2, potential-free inputs, filter 10 µs, 2-wire system |
ES1034 | 4-channel digital input terminal 24 V DC for type 1 sensors, IEC 61131-2, potential-free inputs, filter 10 µs, 2-wire system |
EL1052 | 2-channel digital input terminal NAMUR, DC switching amplifier for NAMUR sensors according to EN 60947-5-6 |
ES1052 | 2-channel digital input terminal NAMUR, DC switching amplifier for NAMUR sensors according to EN 60947-5-6 |
EL1054 | 4-channel digital input terminal NAMUR, DC switching amplifier for NAMUR sensors according to EN 60947-5-6 |
ES1054 | 4-channel digital input terminal NAMUR, DC switching amplifier for NAMUR sensors according to EN 60947-5-6 |
EL1084 | 4-channel digital input terminal 24 V DC, negative switching, filter 3.0 ms, 2-wire system |
ES1084 | 4-channel digital input terminal 24 V DC, negative switching, filter 3.0 ms, 2-wire system |
EL1088 | 8-channel digital input terminal 24 V DC, negative switching, filter 3.0 ms, 1-wire system |
ES1088 | 8-channel digital input terminal 24 V DC, negative switching, filter 3.0 ms, 1-wire system |
EL1094 | 4-channel digital input terminal 24 V DC, negative switching, filter 10 µs, 2-wire system |
ES1094 | 4-channel digital input terminal 24 V DC, negative switching, filter 10 µs, 2-wire system |
EL1098 | 8-channel digital input terminal 24 V DC, negative switching, filter 10 µs, 1-wire system |
ES1098 | 8-channel digital input terminal 24 V DC, negative switching, filter 10 µs, 1-wire system |
EL1104 | 4-channel digital input terminal 24 V DC, filter 3.0 ms, 2 inputs 3-wire system, 2 inputs 1-wire system |
ES1104 | 4-channel digital input terminal 24 V DC, filter 3.0 ms, 2 inputs 3-wire system, 2 inputs 1-wire system |
EL1114 | 4-channel digital input terminal 24 V DC, filter 10 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
ES1114 | 4-channel digital input terminal 24 V DC, filter 10 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
EL1124 | 4-channel digital input terminal 5 V DC, filter 0.05 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
ES1124 | 4-channel digital input terminal 5 V DC, filter 0.05 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
EL1134 | 4-channel digital input terminal 48 V DC, filter 10 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
ES1134 | 4-channel digital input terminal 48 V DC, filter 10 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
EL1144 | 4-channel digital input terminal 12 V DC, filter 10 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
ES1144 | 4-channel digital input terminal 12 V DC, filter 10 µs, 2 inputs 3-wire system, 2 inputs 1-wire system |
EL1202 | 2-channel digital input terminal 24 V DC, TON/TOFF 1 μs |
ES1202 | 2-channel digital input terminal 24 V DC, TON/TOFF 1 μs |
EL1252 | 2-channel digital input terminal 24 V DC, filter 1 µs, with timestamp |
ES1252 | 2-channel digital input terminal 24 V DC, filter 1 µs, with timestamp |
EL1252-0050 | 2-channel digital input terminal 5 V DC, filter 1 µs, with time stamp |
EL1258 | 8-channel digital input terminal 24 V DC, filter 1 µs, with timestamp |
EL1259 | 8-channel digital input terminal 24 V DC, filter 1 µs, type 3, + 8-channel digital output terminal 24 V DC, 0.5 A, 1-wire system, timestamp |
EL1262 | 2-channel digital input terminal 24 V DC, filter 1 µs, with oversampling |
ES1262 | 2-channel digital input terminal 24 V DC, filter 1 µs, with oversampling |
EL1262-0050 | 2-channel digital input terminal 5 V DC, filter 1 µs, with oversampling |
EL1382 | 2-channel digital input terminal thermistor, filter 30 ms |
ES1382 | 2-channel digital input terminal thermistor, filter 30 ms |
EL1502 | Up/down counter 24 V DC, 100 kHz, 32 bit counter depth |
ES1502 | Up/down counter 24 V DC, 100 kHz, 32 bit counter depth |
EL1512 | 2-channel, up/down counter, 24 V DC, 1 kHz, 16 bit counter |
ES1512 | 2-channel, up/down counter, 24 V DC, 1 kHz, 16 bit counter |
EL1702 | 2-channel digital input terminal 120 V AC…230 V AC, 4-wire system |
ES1702 | 2-channel digital input terminal 120 V AC…230 V AC, 4-wire system |
EL1702-0020 | 2-channel digital input terminal 220 V DC, 4-wire system |
ES1702-0020 | 2-channel digital input terminal 220 V DC, 4-wire system |
EL1712 | 2-channel digital input terminal 120 V AC/DC, 4-wire system |
ES1712 | 2-channel digital input terminal 120 V AC/DC, 4-wire system |
EL1712-0020 | 2-channel digital input terminal 120 V DC, 4-wire system |
ES1712-0020 | 2-channel digital input terminal 120 V DC, 4-wire system |
EL1722 | 2-channel digital input terminal 120 V AC…230 V AC, no power contacts, 4-wire system |
ES1722 | 2-channel digital input terminal 120 V AC…230 V AC, no power contacts, 4-wire system |
EL1804 | 4-channel digital input terminal 24 V DC, filter 3.0 ms, 3-wire system |
EL1808 | 8-channel digital input terminal 24 V DC, filter 3.0 ms, 2-wire system |
EL1809 | 16-channel digital input terminal 24 V DC, filter 3.0 ms, type 3 |
EL1814 | 4-channel digital input terminal 24 V DC, filter 10 µs, 3-wire system |
EL1819 | 16-channel digital input terminal 24 V DC, filter 10 µs, type 3 |
EL1859 | 8-channel digital input terminal 24 V DC, filter 3.0 ms, type 3, + 8-channel digital output terminal 24 V DC, 0.5 A, 1-wire system |
EL1862 | 16-channel digital input terminal 24 V DC, filter 3.0 ms, flat-ribbon cable connection, type 3 |
EL1862-0010 | 16-channel digital input terminal 24 V DC, filter 3.0 ms, flat-ribbon cable connection, switching to ground potential |
EL1872 | 16-channel digital input terminal 24 V DC, filter 10 µs, flat-ribbon cable connection, type 3 |
EL1889 | 16-channel digital input terminal 24 V DC, filter 3.0 ms, switching to ground potential |
EL1904 | 4-channel digital input terminal, TwinSAFE, 24 V DC |
EL2002 | 2-channel digital output terminal 24 V DC, 0.5 A, 4-wire system |
ES2002 | 2-channel digital output terminal 24 V DC, 0.5 A, 4-wire system |
EL2004 | 4-channel digital output terminal 24 V DC, 0.5 A, 2-wire system |
ES2004 | 4-channel digital output terminal 24 V DC, 0.5 A, 2-wire system |
EL2008 | 8-channel digital output terminal 24 V DC, 0.5 A, 1-wire system |
ES2008 | 8-channel digital output terminal 24 V DC, 0.5 A, 1-wire system |
EL2014 | 4-channel digital output terminal 24 V DC, 0.5 A, 1-wire system, with diagnostics |
EL2022 | 2-channel digital output terminal 24 V DC, 2 A, 4-wire system |
ES2022 | 2-channel digital output terminal 24 V DC, 2 A, 4-wire system |
EL2024 | 4-channel digital output terminal 24 V DC, 2 A, 2-wire system |
ES2024 | 4-channel digital output terminal 24 V DC, 2 A, 2-wire system |
EL2024-0010 | 4-channel digital output terminal 12 V DC, 2 A, 2-wire system |
EL2032 | 2-channel digital output terminal 24 V DC, 2 A, with diagnostics, 4-wire system |
ES2032 | 2-channel digital output terminal 24 V DC, 2 A, with diagnostics, 4-wire system |
EL2034 | 4-channel digital output terminal 24 V DC, 2 A, with diagnostics, 2-wire system |
ES2034 | 4-channel digital output terminal 24 V DC, 2 A, with diagnostics, 2-wire system |
EL2042 | 2-channel digital output terminal 24 V DC, 2 x 4 A/1 x 8 A, 3-wire system |
ES2042 | 2-channel digital output terminal 24 V DC, 2 x 4 A/1 x 8 A, 3-wire system |
EL2084 | 4-channel digital output terminal 24 V DC, negative switching, 0.5 A, 2-wire system |
ES2084 | 4-channel digital output terminal 24 V DC, negative switching, 0.5 A, 2-wire system |
EL2088 | 8-channel digital output terminal 24 V DC, 0.5 A, negative switching, 1-wire system |
ES2088 | 8-channel digital output terminal 24 V DC, 0.5 A, negative switching, 1-wire system |
EL2124 | 4-channel digital output terminal 5 V DC, 0.02 A, 2 outputs 3-wire system, 2 outputs 1-wire system |
ES2124 | 4-channel digital output terminal 5 V DC, 0.02 A, 2 outputs 3-wire system, 2 outputs 1-wire system |
EL2202 | 2-channel digital output terminal 24 V DC, TON/TOFF 1 μs, push-pull outputs |
ES2202 | 2-channel digital output terminal 24 V DC, TON/TOFF 1 μs, push-pull outputs |
EL2212 | 2-channel digital output terminal 24…72 V DC with overexcitation, multi-timestamp |
ES2212 | 2-channel digital output terminal 24…72 V DC with overexcitation, multi-timestamp |
EL2252 | 2-channel digital output terminal 24 V DC, 0.5 A, 4-wire system, high-speed outputs with timestamp |
ES2252 | 2-channel digital output terminal 24 V DC, 0.5 A, 4-wire system, high-speed outputs with timestamp |
EL2258 | 8-channel digital output terminal 24 V DC, 0.5 A, 2-wire system, high-speed outputs with timestamp |
EL2262 | 2-channel digital output terminal 24 V DC, 0.5 A, 4-wire system, high-speed outputs with oversampling |
ES2262 | 2-channel digital output terminal 24 V DC, 0.5 A, 4-wire system, high-speed outputs with oversampling |
EL2502 | 2-channel pulse width output terminal 24 V DC, 1 A, 4-wire system |
ES2502 | 2-channel pulse width output terminal 24 V DC, 1 A, 4-wire system |
EL2521 | 1-channel pulse train output terminal, 2 RS422 outputs (5 V level) |
ES2521 | 1-channel pulse train output terminal, 2 RS422 outputs (5 V level) |
Một số Module Beckhoff TMP đã cung cấp tại thị trường Việt Nam :
- EL1104, EL1114, EL1124, EL1134 Beckhoff
- EL1084, EL1088, EL1094, EL1098 Beckhoff
- EL1052, ELX1052, EL1054, ELX1054 Beckhoff
- EL1014, EL1018, EL1024, EL1034 Beckhoff
- EL1002, EL1004, EL1008, EL1012 Beckhoff
3. Motion
a. Servo Drives Beckhoff
AX5101-0000-0000 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 1.5 A, EtherCAT interface, hardware version 1.0 |
AX5103-0000-0000 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 3 A, EtherCAT interface, hardware version 1.0 |
AX5106-0000-0000 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 6 A, EtherCAT interface, hardware version 1.0 |
AX5112-0000-0000 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 12 A, EtherCAT interface, hardware version 1.0 |
AX5118-0000-0000 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 18 A, EtherCAT interface, hardware version 1.0 |
AX5125-0000-0000 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 25 A, EtherCAT interface, hardware version 1.0 |
AX5101-0000-0200 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 1.5 A, EtherCAT interface, OCT, hardware version 2.0, firmware version 2.06 |
AX5101-0000-0202 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 1.5 A, EtherCAT interface, OCT, hardware version 2.0, firmware version ≥ 2.10 |
AX5103-0000-0200 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 3 A, EtherCAT interface, OCT, hardware version 2.0, firmware version 2.06 |
AX5103-0000-0202 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 3 A, EtherCAT interface, OCT, hardware version 2.0, firmware version ≥ 2.10 |
AX5106-0000-0200 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 6 A, EtherCAT interface, OCT, hardware version 2.0, firmware version version 2.06 |
AX5106-0000-0202 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 6 A, EtherCAT interface, OCT, hardware version 2.0, firmware version ≥ 2.10 |
AX5112-0000-0200 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 12 A, EtherCAT interface, OCT, hardware version 2.0, firmware version 2.06 |
AX5112-0000-0202 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 12 A, EtherCAT interface, OCT, hardware version 2.0, firmware version ≥ 2.10 |
AX5118-0000-0200 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 18 A, EtherCAT interface, OCT, hardware version 2.0, firmware version 2.06 |
AX5118-0000-0202 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 18 A, EtherCAT interface, OCT, hardware version 2.0, firmware version ≥ 2.10 |
AX5125-0000-0200 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 25 A, EtherCAT interface, OCT, hardware version 2.0, firmware version 2.06 |
AX5125-0000-0202 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 25 A, EtherCAT interface, OCT, hardware version 2.0, firmware version ≥ 2.10 |
AX5140-0000-0200 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 40 A, EtherCAT interface, OCT, hardware version 2.0, firmware version 2.06 |
AX5140-0000-0202 | Digital Compact Servo Drive, 1-axis module, 100…480 V AC, rated output current 40 A, EtherCAT interface, OCT, hardware version 2.0, firmware version ≥ 2.10 |
b. Synchronous Servomotors
ZK4500-8022-0050 | E |
xample for 5 m length | |
ZK4501-8022-xxxx | Motor cable extension for motor cable ZK4500-8022-xxxx |
ZK4500-8062-0050 | Example for 5 m length |
ZK4501-8062-xxxx | extension cable |
ZK4500-8003-0050 | Example for 5 m length |
ZK4501-8003-xxxx | Motor cable extension for motor cable ZK4500-8003-xxxx / ZK4500-8023-xxxx |
ZK4500-8023-0050 | Example for 5 m length |
ZK4501-8023-xxxx | Motor cable extension for motor cable ZK4500-8003-xxxx / ZK4500-8023-xxxx |
ZK4500-8063-0050 | Example for 5 m length |
ZK4501-8063-xxxx | extension cable |
ZK4500-8004-0050 | Example for 5 m length |
ZK4501-8004-xxxx | Motor cable extension for motor cable ZK4500-8004-xxxx / ZK4500-8024-xxxx |
ZK4500-8024-0050 | Example for 5 m length |
ZK4501-8024-xxxx | Motor cable extension for motor cable ZK4500-8004-xxxx / ZK4500-8024-xxxx |
ZK4500-8064-0050 | Example for 5 m length |
ZK4501-8064-xxxx | extension cable |
ZK4500-8025-0050 | example for 5 m length |
ZK4501-8025-xxxx | extension cable |
ZK4500-8027-0050 | Example for 5 m length |
ZK4501-8027-xxxx | Motor cable extension for motor cable ZK4500-8027-xxxx / ZK4504-8027-xxxx |
ZK4504-8027-0050 | Example for 5 m length |
ZK4501-8027-xxxx | Motor cable extension for motor cable ZK4500-8027-xxxx / ZK4504-8027-xxxx |
ZK4510-8020-0050 | Example for 5 m length |
ZK4511-8020-xxxx | Encoder cable extension for ZK4510-8020-xxxx |
ZK4500-8022-0050 | Example for 5 m length |
ZK4509-8022-zzzz | Motor cable, not assembled, price per metre |
ZK4501-8022-xxxx | Motor cable extension for motor cable ZK4500-8022-xxxx |
ZK4500-0003-0050 | Example for 5 m length |
ZK4502-0003-xxxx | Motor cable ≥ 25 m if motor choke is required |
ZK4509-0003-zzzz | Motor cable, not assembled, price per metre |
ZK4501-0003-xxxx | Motor cable extension for motor cable ZK4500-00x3-xxxx / ZK4502-00x3-xxxx |
ZK4500-0023-0050 | Example for 5 m length |
ZK4502-0023-xxxx | Motor cable ≥ 25 m if motor choke is required |
ZK4509-0023-zzzz | Motor cable, not assembled, price per metre |
ZK4501-0023-xxxx | Motor cable extension for motor cable ZK4500-00x3-xxxx / ZK4502-00x3-xxxx |
ZK4500-0004-0050 | Example for 5 m length |
ZK4502-0004-xxxx | Motor cable ≥ 25 m if motor choke is required |
ZK4509-0004-zzzz | Motor cable, not assembled, price per metre |
ZK4501-0004-xxxx | Motor cable extension for motor cable ZK4500-00x4-xxxx / ZK4502-00x4-xxxx |
ZK4500-0024-0050 | Example for 5 m length |
ZK4502-0024-xxxx | Motor cable ≥ 25 m if motor choke is required |
ZK4509-0024-zzzz | Motor cable, not assembled, price per metre |
ZK4501-0024-xxxx | Motor cable extension for motor cable ZK4500-00x4-xxxx / ZK4502-00x4-xxxx |
c. Linear Servomotors
AM8011-wBy0 | Servomotor, 230 V AC, Mo= 0.20 Nm, Io= 0.76 A, nn= 8000 min-1 |
AM8011-wBy1 | Servomotor, 230 V AC, Mo= 0.215 Nm, Io= 0.80 A, nn= 8000 min-1, with holding brake |
AM8012-wCy0 | Servomotor, 230 V AC, Mo= 0.38 Nm, Io= 1.30 A, nn= 8000 min-1 |
AM8012-wCy1 | Servomotor, 230 V AC, Mo= 0.38 Nm, Io= 1.30 A, nn= 8000 min-1, with holding brake |
AM8013-wDy0 | Servomotor, 230 V AC, Mo= 0.52 Nm, Io= 1.65 A, nn= 8000 min-1 |
AM8013-wDy1 | Servomotor, 230 V AC, Mo= 0.55 Nm, Io= 1.60 A, nn= 8000 min-1, with holding brake |
AM8021-wBy0 | Servomotor, 400 V AC, Mo= 0.50 Nm, Io= 0.85 A, nn= 8000 min-1 |
AM8021-wBy1 | Servomotor, 400 V AC, Mo= 0.50 Nm, Io= 0.85 A, nn= 8000 min-1, with holding brake |
AM8021-wDy0 | Servomotor, 400 V AC, Mo= 0.50 Nm, Io= 1.60 A, nn= 9000 min-1 |
AM8021-wDy1 | Servomotor, 400 V AC, Mo= 0.50 Nm, Io= 1.60 A, nn= 9000 min-1, with holding brake |
AM8022-wDy0 | Servomotor, 400 V AC, Mo= 0.80 Nm, Io= 1.50 A, nn= 8000 min-1 |
AM8022-wDy1 | Servomotor, 400 V AC, Mo= 0.80 Nm, Io= 1.50 A, nn= 8000 min-1, with holding brake |
AM8022-wEy0 | Servomotor, 400 V AC, Mo= 0.80 Nm, Io= 2.44 A, nn= 9000 min-1 |
AM8022-wEy1 | Servomotor, 400 V AC, Mo= 0.80 Nm, Io= 2.44 A, nn= 9000 min-1, with holding brake |
AM8023-wEy0 | Servomotor, 400 V AC, Mo= 1.20 Nm, Io= 2.20 A, nn= 8000 min-1 |
AM8023-wEy1 | Servomotor, 400 V AC, Mo= 1.20 Nm, Io= 2.20 A, nn= 8000 min-1, with holding brake |
AM8023-wFy0 | Servomotor, 400 V AC, Mo= 1.20 Nm, Io= 3.40 A, nn= 9000 min-1 |
AM8023-wFy1 | Servomotor, 400 V AC, Mo= 1.20 Nm, Io= 3.40 A, nn= 9000 min-1, with holding brake |
AM8031-wCy0 | Servomotor, 400 V AC, Mo= 1.37 Nm, Io= 1.00 A, nn= 3000 min-1 |
AM8031-wCy1 | Servomotor, 400 V AC, Mo= 1.37 Nm, Io= 1.00 A, nn= 3000 min-1, with holding brake |
AM8031-wDy0 | Servomotor, 400 V AC, Mo= 1.38 Nm, Io= 1.95 A, nn= 6000 min-1 |
AM8031-wDy1 | Servomotor, 400 V AC, Mo= 1.38 Nm, Io= 1.95 A, nn= 6000 min-1, with holding brake |
AM8031-wFy0 | Servomotor, 400 V AC, Mo= 1.40 Nm, Io= 3.20 A, nn= 9000 min-1 |
AM8031-wFy1 | Servomotor, 400 V AC, Mo= 1.40 Nm, Io= 3.20 A, nn= 9000 min-1, with holding brake |
AM8032-wDy0 | Servomotor, 400 V AC, Mo= 2.38 Nm, Io= 1.70 A, nn= 3000 min-1 |
AM8032-wDy1 | Servomotor, 400 V AC, Mo= 2.38 Nm, Io= 1.70 A, nn= 3000 min-1, with holding brake |
AM8032-wEy0 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 2.95 A, nn= 6000 min-1 |
AM8032-wEy1 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 2.95 A, nn= 6000 min-1, with holding brake |
AM8032-wHy0 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 5.10 A, nn= 9000 min-1 |
AM8032-wHy1 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 5.10 A, nn= 9000 min-1, with holding brake |
AM8033-wEy0 | Servomotor, 400 V AC, Mo= 3.20 Nm, Io= 2.10 A, nn= 3000 min-1 |
AM8033-wEy1 | Servomotor, 400 V AC, Mo= 3.20 Nm, Io= 2.10 A, nn= 3000 min-1, with holding brake |
AM8033-wFy0 | Servomotor, 400 V AC, Mo= 3.22 Nm, Io= 4.10 A, nn= 6000 min-1 |
AM8033-wFy1 | Servomotor, 400 V AC, Mo= 3.22 Nm, Io= 4.10 A, nn= 6000 min-1, with holding brake |
AM8033-wJy0 | Servomotor, 400 V AC, Mo= 3.22 Nm, Io= 6.80 A, nn= 9000 min-1 |
AM8033-wJy1 | Servomotor, 400 V AC, Mo= 3.22 Nm, Io= 6.80 A, nn= 9000 min-1, with holding brake |
AM8041-wDy0 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 1.65 A, nn= 3000 min-1 |
AM8041-wDy1 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 1.65 A, nn= 3000 min-1, with holding brake |
AM8041-wEy0 | Servomotor, 400 V AC, Mo= 2.45 Nm, Io= 3.00 A, nn= 6000 min-1 |
AM8041-wEy1 | Servomotor, 400 V AC, Mo= 2.45 Nm, Io= 3.00 A, nn= 6000 min-1, with holding brake |
AM8041-wHy0 | Servomotor, 400 V AC, Mo= 2.40 Nm, Io= 5.25 A, nn= 8000 min-1 |
AM8041-wHy1 | Servomotor, 400 V AC, Mo= 2.40 Nm, Io= 5.25 A, nn= 8000 min-1, with holding brake |
AM8042-wEy0 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 2.15 A, nn= 2500 min-1 |
AM8042-wEy1 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 2.15 A, nn= 2500 min-1, with holding brake |
AM8042-wFy0 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 4.10 A, nn= 5000 min-1 |
AM8042-wFy1 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 4.10 A, nn= 5000 min-1, with holding brake |
AM8042-wJy0 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 6.90 A, nn= 8000 min-1 |
AM8042-wJy1 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 6.90 A, nn= 8000 min-1, with holding brake |
AM8043-wEy0 | Servomotor, 400 V AC, Mo= 5.65 Nm, Io= 2.90 A, nn= 2500 min-1 |
AM8043-wEy1 | Servomotor, 400 V AC, Mo= 5.65 Nm, Io= 2.90 A, nn= 2500 min-1, with holding brake |
AM8043-wHy0 | Servomotor, 400 V AC, Mo= 5.65 Nm, Io= 5.40 A, nn= 5000 min-1 |
AM8043-wHy1 | Servomotor, 400 V AC, Mo= 5.65 Nm, Io= 5.40 A, nn= 5000 min-1, with holding brake |
AM8043-wKy0 | Servomotor, 400 V AC, Mo= 5.60 Nm, Io= 9.30 A, nn= 8000 min-1 |
AM8043-wKy1 | Servomotor, 400 V AC, Mo= 5.60 Nm, Io= 9.30 A, nn= 8000 min-1, with holding brake |
AM8051-wEy0 | Servomotor, 400 V AC, Mo= 4.80 Nm, Io= 2.70 A, nn= 2500 min-1 |
AM8051-wEy1 | Servomotor, 400 V AC, Mo= 4.80 Nm, Io= 2.70 A, nn= 2500 min-1, with holding brake |
AM8051-wGy0 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 4.75 A, nn= 5000 min-1 |
AM8051-wGy1 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 4.75 A, nn= 5000 min-1, with holding brake |
AM8051-wKy0 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 8.50 A, nn= 8000 min-1 |
AM8051-wKy1 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 8.50 A, nn= 8000 min-1, with holding brake |
AM8052-wFy0 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 3.30 A, nn= 2000 min-1 |
AM8052-wFy1 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 3.30 A, nn= 2000 min-1 , with holding brake |
AM8052-wJy0 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 6.30 A, nn= 4000 min-1 |
AM8052-wJy1 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 6.30 A, nn= 4000 min-1, with holding brake |
AM8052-wLy0 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 11.30 A, nn= 7300 min-1 |
AM8052-wLy1 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 11.30 A, nn= 7300 min-1, with holding brake |
AM8053-wGy0 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 4.70 A, nn= 2000 min-1 |
AM8053-wGy1 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 4.70 A, nn= 2000 min-1 , with holding brake |
AM8053-wKy0 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 8.80 A, nn= 4000 min-1 |
AM8053-wKy1 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 8.80 A, nn= 4000 min-1, with holding brake |
AM8053-wNy0 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 15.60 A, nn= 7000 min-1 |
AM8053-wNy1 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 15.60 A, nn= 7000 min-1, with holding brake |
AM8061-wGy0 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 4.00 A, nn= 1500 min-1 |
AM8061-wGy1 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 4.00 A, nn= 1500 min-1, with holding brake |
AM8061-wJy0 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 7.80 A, nn= 3000 min-1 |
AM8061-wJy1 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 7.80 A, nn= 3000 min-1, with holding brake |
AM8061-wMy0 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 13.10 A, nn= 5000 min-1 |
AM8061-wMy1 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 13.10 A, nn= 5000 min-1, with holding brake |
AM8062-wJy0 | Servomotor, 400 V AC, Mo= 21.10 Nm, Io= 6.20 A, nn= 1500 min-1 |
AM8062-wJy1 | Servomotor, 400 V AC, Mo= 21.10 Nm, Io= 6.20 A, nn= 1500 min-1, with holding brake |
AM8062-wLy0 | Servomotor, 400 V AC, Mo= 21.10 Nm, Io= 12.40 A, nn= 3000 min-1 |
AM8062-wLy1 | Servomotor, 400 V AC, Mo= 21.10 Nm, Io= 12.40 A, nn= 3000 min-1, with holding brake |
AM8062-wPy0 | Servomotor, 400 V AC, Mo= 21.10 Nm, Io= 20.30 A, nn= 5000 min-1 |
AM8062-wPy1 | Servomotor, 400 V AC, Mo= 21.10 Nm, Io= 20.30 A, nn= 5000 min-1, with holding brake |
AM8063-wKy0 | Servomotor, 400 V AC, Mo= 29.00 Nm, Io= 8.70 A, nn= 1500 min-1 |
AM8063-wKy1 | Servomotor, 400 V AC, Mo= 29.00 Nm, Io= 8.70 A, nn= 1500 min-1, with holding brake |
AM8063-wNy0 | Servomotor, 400 V AC, Mo= 29.00 Nm, Io= 17.20 A, nn= 3000 min-1 |
AM8063-wNy1 | Servomotor, 400 V AC, Mo= 29.00 Nm, Io= 17.20 A, nn= 3000 min-1, with holding brake |
AM8063-wRy0 | Servomotor, 400 V AC, Mo= 29.00 Nm, Io= 29.50 A, nn= 4000 min-1 |
AM8063-wRy1 | Servomotor, 400 V AC, Mo= 29.00 Nm, Io= 29.50 A, nn= 4000 min-1, with holding brake |
AM8071-wKy1 | Servomotor, 400 V AC, Mo= 31.8 Nm, Io= 9.6 A, nn= 1500 min-1, with holding brake |
AM8071-wKy0 | Servomotor, 400 V AC, Mo= 31.8 Nm, Io= 9.6 A, nn= 1500 min-1 |
AM8071-wNy1 | Servomotor, 400 V AC, Mo= 31.80 Nm, Io= 17.80 A, nn= 3000 min-1, with holding brake |
AM8071-wNy0 | Servomotor, 400 V AC, Mo= 31.80 Nm, Io= 17.80 A, nn= 3000 min-1 |
AM8071-wRy1 | Servomotor, 400 V AC, Mo= 29.0 Nm, Io= 28.2 A, nn= 4000 min-1, with holding brake |
AM8071-wRy0 | Servomotor, 400 V AC, Mo= 29.0 Nm, Io= 28.2 A, nn= 4000 min-1 |
AM8072-wLy1 | Servomotor, 400 V AC, Mo= 54.6 Nm, Io= 11.1 A, nn= 1000 min-1, with holding brake |
AM8072-wLy0 | Servomotor, 400 V AC, Mo= 54.6 Nm, Io= 11.1 A, nn= 1000 min-1 |
AM8072-wPy1 | Servomotor, 400 V AC, Mo= 54.60 Nm, Io= 20.60 A, nn= 2000 min-1 , with holding brake |
AM8072-wPy0 | Servomotor, 400 V AC, Mo= 54.60 Nm, Io= 20.60 A, nn= 2000 min-1 |
AM8072-wTy1 | Servomotor, 400 V AC, Mo= 50.0 Nm, Io= 39 A, nn= 3000 min-1, with holding brake |
AM8072-wTy0 | Servomotor, 400 V AC, Mo= 50.0 Nm, Io= 39 A, nn= 3000 min-1 |
AM8073-wNy1 | Servomotor, 400 V AC, Mo= 72.6 Nm, Io= 14.7 A, nn= 1000 min-1, with holding brake |
AM8073-wNy0 | Servomotor, 400 V AC, Mo= 72.6 Nm, Io= 14.7 A, nn= 1000 min-1 |
AM8073-wQy1 | Servomotor, 400 V AC, Mo= 72.6 Nm, Io= 27.90 A, nn= 2000 min-1 , with holding brake |
AM8073-wQy0 | Servomotor, 400 V AC, Mo= 72.6 Nm, Io= 27.90 A, nn= 2000 min-1 |
AM8073-wTy1 | Servomotor, 400 V AC, Mo= 70.0 Nm, Io= 45.6 A, nn= 3000 min-1, with holding brake |
AM8073-wTy0 | Servomotor, 400 V AC, Mo= 70.0 Nm, Io= 45.6 A, nn= 3000 min-1 |
AM8074-wNy0 | Servomotor, 400 V AC, Mo = 92 Nm, Io = 17.9 A, nn = 1000 min-1 |
AM8074-wTy0 | Servomotor, 400 V AC, Mo = 92 Nm, Io = 34.9 A, nn = 2000 min-1 |
AM8074-wRy0 | Servomotor, 400 V AC, Mo = 92 Nm, Io = 49.8 A, nn = 2500 min-1 |
AM8051-wFyB | Servomotor, 400 V AC, Mo= 6.2 Nm, Io= 3.5 A, nn= 2500 min-1, forced cooling, with holding brake |
AM8051-wFyA | Servomotor, 400 V AC, Mo= 6.2 Nm, Io= 3.5 A, nn= 2500 min-1, forced cooling |
AM8051-wJyB | Servomotor, 400 V AC, Mo= 6.3 Nm, Io= 5.8 A, nn= 4750 min-1, forced cooling, with holding brake |
AM8051-wJyA | Servomotor, 400 V AC, Mo= 6.3 Nm, Io= 5.8 A, nn= 5000 min-1, forced cooling |
AM8051-wLyB | Servomotor, 400 V AC, Mo= 6.3 Nm, Io= 11.1 A, nn= 8000 min-1, forced cooling, with holding brake |
AM8051-wLyA | Servomotor, 400 V AC, Mo= 6.3 Nm, Io= 11.1 A, nn= 8000 min-1, forced cooling |
AM8052-wGyB | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 4.3 A, nn= 2000 min-1, forced cooling, with holding brake |
AM8052-wGyA | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 4.3 A, nn= 2000 min-1, forced cooling |
AM8052-wKyB | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 8.5 A, nn= 4000 min-1, forced cooling, with holding brake |
AM8052-wKyA | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 8.5 A, nn= 4000 min-1, forced cooling |
AM8052-wNyA | Servomotor, 400 V AC, Mo= 9.6 Nm, Io= 13.6 A, nn= 6000 min-1, forced cooling |
AM8052-wNyB | Servomotor, 400 V AC, Mo= 9.6 Nm, Io= 13.6 A, nn= 6000 min-1, forced cooling, with holding brake |
AM8053-wJyB | Servomotor, 400 V AC, Mo= 15.4 Nm, Io= 6.4 A, nn= 2000 min-1, forced cooling, with holding brake |
AM8053-wJyA | Servomotor, 400 V AC, Mo= 15.4 Nm, Io= 6.4 A, nn= 2000 min-1, forced cooling |
AM8053-wLyB | Servomotor, 400 V AC, Mo= 15.4 Nm, Io= 11.9 A, nn= 4000 min-1, forced cooling, with holding brake |
AM8053-wLyA | Servomotor, 400 V AC, Mo= 15.4 Nm, Io= 11.9 A, nn= 4000 min-1, forced cooling |
AM8053-wPyB | Servomotor, 400 V AC, Mo= 13.3 Nm, Io= 18.6 A, nn= 5000 min-1, forced cooling, with holding brake |
AM8053-wPyA | Servomotor, 400 V AC, Mo= 13.3 Nm, Io= 18.6 A, nn= 5000 min-1, forced cooling |
AM8061-wHyB | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 5.2 A, nn= 1400 min-1, forced cooling, with holding brake |
AM8061-wHyA | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 5.2 A, nn= 1400 min-1, forced cooling |
AM8061-wLyB | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 10.1 A, nn= 3000 min-1, forced cooling, with holding brake |
AM8061-wLyA | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 10.1 A, nn= 3000 min-1, forced cooling |
AM8061-wNyB | Servomotor, 400 V AC, Mo= 15.5 Nm, Io= 15.8 A, nn= 5000 min-1, forced cooling, with holding brake |
AM8061-wNyA | Servomotor, 400 V AC, Mo= 15.5 Nm, Io= 15.8 A, nn= 5000 min-1, forced cooling |
AM8062-wKyB | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 8.7 A, nn= 1400 min-1, forced cooling, with holding brake |
AM8062-wKyA | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 8.7 A, nn= 1400 min-1, forced cooling |
AM8062-wNyB | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 17.4 A, nn=3000 min-1, forced cooling, with holding brake |
AM8062-wNyA | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 17.4 A, nn=3000 min-1, forced cooling |
AM8062-wRyB | Servomotor, 400 V AC, Mo= 28.1 Nm, Io= 28.7 A, nn= 5000 min-1, forced cooling, with holding brake |
AM8062-wRyA | Servomotor, 400 V AC, Mo= 28.1 Nm, Io= 28.7 A, nn= 5000 min-1, forced cooling |
AM8063-wLyA | Servomotor, 400 V AC, Mo= 41.4 Nm, Io= 11.6 A, nn= 1400 min-1, forced cooling |
AM8063-wLyB | Servomotor, 400 V AC, Mo= 41.4 Nm, Io= 11.6 A, nn= 1400 min-1, forced cooling, with holding brake |
AM8063-wQyA | Servomotor, 400 V AC, Mo= 41.4 Nm, Io= 24.0 A, nn= 3000 min-1, forced cooling |
AM8063-wQyB | Servomotor, 400 V AC, Mo= 41.4 Nm, Io= 24.0 A, nn= 3000 min-1, forced cooling, with holding brake |
AM8063-wTyA | Servomotor, 400 V AC, Mo= 40.1 Nm, Io= 39.8 A, nn= 4000 min-1, forced cooling |
AM8063-wTyB | Servomotor, 400 V AC, Mo= 40.1 Nm, Io= 39.8 A, nn= 4000 min-1, forced cooling, with holding brake |
AM8071-wMyB | Servomotor, 400 V AC, Mo= 42.8 Nm, Io= 12.6 A, nn= 1500 min-1, forced cooling, with holding brake |
AM8071-wMyA | Servomotor, 400 V AC, Mo= 42.8 Nm, Io= 12.6 A, nn= 1500 min-1, forced cooling |
AM8071-wPyB | Servomotor, 400 V AC, Mo= 42.8 Nm, Io= 23.8 A, nn= 2900 min-1, forced cooling, with holding brake |
AM8071-wPyA | Servomotor, 400 V AC, Mo= 42.8 Nm, Io= 23.8 A, nn= 2900 min-1, forced cooling |
AM8071-wTyB | Servomotor, 400 V AC, Mo= 41.2 Nm, Io= 41.1 A, nn= 4000 min-1, forced cooling, with holding brake |
AM8071-wTyA | Servomotor, 400 V AC, Mo= 41.2 Nm, Io= 41.1 A, nn= 4000 min-1, forced cooling |
AM8072-wNyA | Servomotor, 400 V AC, Mo= 80.7 Nm, Io= 16.1 A, nn= 1000 min-1, forced cooling |
AM8072-wNyB | Servomotor, 400 V AC, Mo= 80.7 Nm, Io= 16.1 A, nn= 1000 min-1, forced cooling, with holding brake |
AM8072-wRyA | Servomotor, 400 V AC, Mo= 80.7 Nm, Io= 29.2 A, nn= 2000 min-1, forced cooling |
AM8072-wRyB | Servomotor, 400 V AC, Mo= 80.7 Nm, Io= 29.2 A, nn= 2000 min-1, forced cooling, with holding brake |
AM8072-wUyA | Servomotor, 400 V AC, Mo= 74.0 Nm, Io= 53.0 A, nn= 3000 min-1, forced cooling |
AM8072-wUyB | Servomotor, 400 V AC, Mo= 74.0 Nm, Io= 53.0 A, nn= 3000 min-1, forced cooling, with holding brake |
AM8073-wPyA | Servomotor, 400 V AC, Mo= 104.0 Nm, Io= 19.8 A, nn= 1000 min-1, forced cooling |
AM8073-wPyB | Servomotor, 400 V AC, Mo= 104.0 Nm, Io= 19.8 A, nn= 1000 min-1, forced cooling, with holding brake |
AM8073-wRyA | Servomotor, 400 V AC, Mo= 104.0 Nm, Io= 37.4 A, nn= 2000 min-1, forced cooling |
AM8073-wRyB | Servomotor, 400 V AC, Mo= 104.0 Nm, Io= 37.4 A, nn= 2000 min-1, forced cooling, with holding brake |
AM8073-wUyA | Servomotor, 400 V AC, Mo= 95.0 Nm, Io= 66.5 A, nn= 3000 min-1, forced cooling |
AM8073-wUyB | Servomotor, 400 V AC, Mo= 95.0 Nm, Io= 66.5 A, nn= 3000 min-1, forced cooling, with holding brake |
AM8074-wRyA | Servomotor, 400 V AC, Mo = 129 Nm, Io = 25.8 A, nn = 1000 min-1, forced cooling |
AM8074-wTyA | Servomotor, 400 V AC, Mo = 129 Nm, Io = 49.4 A, nn = 2000 min-1, forced cooling |
AM8074-wUyA | Servomotor, 400 V AC, Mo = 129 Nm, Io = 69.2 A, nn = 3000 min-1, forced cooling |
AM8531-wCy0 | Servomotor, 400 V AC, Mo= 1.37 Nm, Io= 1.00 A, nn = 3000 min-1, 1.670 kgcm² |
AM8531-wCy1 | Servomotor, 400 V AC, Mo= 1.37 Nm, Io= 1.00 A, nn = 3000 min-1, 1.760 kgcm², with holding brake |
AM8531-wDy0 | Servomotor, 400 V AC, Mo= 1.38 Nm, Io= 1.95 A, nn = 6000 min-1, 1.670 kgcm² |
AM8531-wDy1 | Servomotor, 400 V AC, Mo= 1.38 Nm, Io= 1.95 A, nn = 6000 min-1, 1.760 kgcm², with holding brake |
AM8531-wFy0 | Servomotor, 400 V AC, Mo= 1.40 Nm, Io= 3.20 A, nn = 9000 min-1, 1.670 kgcm² |
AM8531-wFy1 | Servomotor, 400 V AC, Mo= 1.40 Nm, Io= 3.20 A, nn = 9000 min-1, 1.760 kgcm², with holding brake |
AM8532-wDy0 | Servomotor, 400 V AC, Mo= 2.38 Nm, Io= 1.70 A, nn = 3000 min-1, 2.050 kgcm² |
AM8532-wDy1 | Servomotor, 400 V AC, Mo= 2.38 Nm, Io= 1.70 A, nn = 3000 min-1, 2.150 kgcm², with holding brake |
AM8532-wEy0 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 2.95 A, nn = 6000 min-1, 2.050 kgcm² |
AM8532-wEy1 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 2.95 A, nn = 6000 min-1, 2.150 kgcm², with holding brake |
AM8532-wHy0 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 5.10 A, nn = 9000 min-1, 2.050 kgcm² |
AM8532-wHy1 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 5.10 A, nn = 9000 min-1, 2.150 kgcm², with holding brake |
AM8533-wEy0 | Servomotor, 400 V AC, Mo= 3.20 Nm, Io= 2.10 A, nn = 3000 min-1, 2.440 kgcm² |
AM8533-wFy0 | Servomotor, 400 V AC, Mo= 3.22 Nm, Io= 4.10 A, nn = 6000 min-1, 2.440 kgcm² |
AM8533-wJy0 | Servomotor, 400 V AC, Mo= 3.22 Nm, Io= 6.80 A, nn = 9000 min-1, 2.440 kgcm² |
AM8541-wDy0 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 1.65 A, nn = 3000 min-1, 4.620 kgcm² |
AM8541-wDy1 | Servomotor, 400 V AC, Mo= 2.37 Nm, Io= 1.65 A, nn = 3000 min-1, 5.270 kgcm², with holding brake |
AM8541-wEy0 | Servomotor, 400 V AC, Mo= 2.45 Nm, Io= 3.00 A, nn = 6000 min-1, 4.620 kgcm² |
AM8541-wEy1 | Servomotor, 400 V AC, Mo= 2.45 Nm, Io= 3.00 A, nn = 6000 min-1, 5.270 kgcm², with holding brake |
AM8541-wHy0 | Servomotor, 400 V AC, Mo= 2.40 Nm, Io= 5.25 A, nn = 8000 min-1, 4.620 kgcm² |
AM8541-wHy1 | Servomotor, 400 V AC, Mo= 2.40 Nm, Io= 5.25 A, nn = 8000 min-1, 5.270 kgcm², with holding brake |
AM8542-wEy0 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 2.15 A, nn = 2500 min-1, 5.510 kgcm² |
AM8542-wEy1 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 2.15 A, nn = 2500 min-1, 6.170 kgcm², with holding brake |
AM8542-wFy0 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 4.10 A, nn = 5000 min-1, 5.510 kgcm² |
AM8542-wFy1 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 4.10 A, nn = 5000 min-1, 6.170 kgcm², with holding brake |
AM8542-wJy0 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 6.90 A, nn = 8000 min-1, 5.510 kgcm² |
AM8542-wJy1 | Servomotor, 400 V AC, Mo= 4.10 Nm, Io= 6.90 A, nn = 8000 min-1, 6.170 kgcm², with holding brake |
AM8543-wEy0 | Servomotor, 400 V AC, Mo= 5.65 Nm, Io= 2.90 A, nn = 2500 min-1, 6.410 kgcm² |
AM8543-wHy0 | Servomotor, 400 V AC, Mo= 5.65 Nm, Io= 5.4 A, nn = 5000 min-1, 6.410 kgcm² |
AM8543-wKy0 | Servomotor, 400 V AC, Mo= 5.60 Nm, Io= 9.3 A, nn = 8000 min-1, 6.410 kgcm² |
AM8551-wEy0 | Servomotor, 400 V AC, Mo= 4.80 Nm, Io= 2.7 A, nn = 2500 min-1, 8.750 kgcm² |
AM8551-wEy1 | Servomotor, 400 V AC, Mo= 4.80 Nm, Io= 2.7 A, nn = 2500 min-1, 9.410 kgcm², with holding brake |
AM8551-wGy0 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 4.75 A, nn = 5000 min-1, 8.750 kgcm² |
AM8551-wGy1 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 4.75 A, nn = 5000 min-1, 9.410 kgcm², with holding brake |
AM8551-wKy0 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 8.50 A, nn = 8000 min-1, 8.750 kgcm² |
AM8551-wKy1 | Servomotor, 400 V AC, Mo= 4.90 Nm, Io= 8.50 A, nn = 8000 min-1, 9.410 kgcm², with holding brake |
AM8552-wFy0 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 3.30 A, nn = 2000 min-1, 10.600 kgcm² |
AM8552-wFy1 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 3.30 A, nn = 2000 min-1, 11.300 kgcm², with holding brake |
AM8552-wJy0 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 6.30 A, nn = 4000 min-1, 10.600 kgcm² |
AM8552-wJy1 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 6.30 A, nn = 4000 min-1, 11.300 kgcm², with holding brake |
AM8552-wLy0 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 11.30 A, nn = 7300 min-1, 10.600 kgcm² |
AM8552-wLy1 | Servomotor, 400 V AC, Mo= 8.20 Nm, Io= 11.30 A, nn = 7300 min-1, 11.300 kgcm², with holding brake |
AM8553-wGy0 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 4.70 A, nn = 2000 min-1, 12.400 kgcm² |
AM8553-wKy0 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 8.80 A, nn = 4000 min-1, 12.400 kgcm² |
AM8553-wNy0 | Servomotor, 400 V AC, Mo= 11.40 Nm, Io= 15.6 A, nn = 7000 min-1, 12.400 kgcm² |
AM8561-wGy0 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 4.0 A, nn = 1500 min-1, 48.200 kgcm² |
AM8561-wGy1 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 4.0 A, nn = 1500 min-1, 50.600 kgcm², with holding brake |
AM8561-wJy0 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 7.8 A, nn = 3000 min-1, 48.200 kgcm² |
AM8561-wJy1 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 7.8 A, nn = 3000 min-1, 50.600 kgcm², with holding brake |
AM8561-wMy0 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 13.1 A, nn = 5000 min-1, 48.200 kgcm² |
AM8561-wMy1 | Servomotor, 400 V AC, Mo= 12.80 Nm, Io= 13.1 A, nn = 5000 min-1, 50.600 kgcm², with holding brake |
AM8562-wJy0 | Servomotor, 400 V AC, Mo= 21.1 Nm, Io= 6.20 A, nn = 1500 min-1, 57.100 kgcm² |
AM8562-wJy1 | Servomotor, 400 V AC, Mo= 21.1 Nm, Io= 6.20 A, nn = 1500 min-1, 59.600 kgcm², with holding brake |
AM8562-wLy0 | Servomotor, 400 V AC, Mo= 21.1 Nm, Io= 12.40 A, nn = 3000 min-1, 57.100 kgcm² |
AM8562-wLy1 | Servomotor, 400 V AC, Mo= 21.1 Nm, Io= 12.40 A, nn = 3000 min-1, 59.600 kgcm², with holding brake |
AM8562-wPy0 | Servomotor, 400 V AC, Mo= 21.1 Nm, Io= 20.30 A, nn = 5000 min-1, 57.100 kgcm² |
AM8562-wPy1 | Servomotor, 400 V AC, Mo= 21.1 Nm, Io= 20.30 A, nn = 5000 min-1, 59.600 kgcm², with holding brake |
AM8563-wKy0 | Servomotor, 400 V AC, Mo= 29.0 Nm, Io= 8.70 A, nn = 1500 min-1, 66.100 kgcm² |
AM8563-wNy0 | Servomotor, 400 V AC, Mo= 29.0 Nm, Io= 17.20 A, nn = 3000 min-1, 66.100 kgcm² |
AM8563-wRy0 | Servomotor, 400 V AC, Mo= 29.0 Nm, Io= 29.50 A, nn = 4000 min-1, 66.100 kgcm² |
AM8551-wFyA | Servomotor, 400 V AC, Mo= 6.20 Nm, Io= 3.50 A, nn= 2500 min-1, 8.75 kgcm², forced cooling |
AM8551-wFyB | Servomotor, 400 V AC, Mo= 6.20 Nm, Io= 3.50 A, nn= 2500 min-1, 9.40 kgcm², forced cooling, with holding brake |
AM8551-wJyA | Servomotor, 400 V AC, Mo= 6.30 Nm, Io= 5.80 A, nn= 4750 min-1, 8.75 kgcm², forced cooling |
AM8551-wJyB | Servomotor, 400 V AC, Mo= 6.30 Nm, Io= 5.80 A, nn= 4750 min-1, 9.40 kgcm², forced cooling, with holding brake |
AM8551-wLyA | Servomotor, 400 V AC, Mo= 6.30 Nm, Io= 11.1 A, nn= 8000 min-1, 8.75 kgcm², forced cooling |
AM8551-wLyB | Servomotor, 400 V AC, Mo= 6.30 Nm, Io= 11.1 A, nn= 8000 min-1, 9.40 kgcm², forced cooling, with holding brake |
AM8552-wGyA | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 4.30 A, nn= 2000 min-1, 10.6 kgcm², forced cooling |
AM8552-wGyB | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 4.30 A, nn= 2000 min-1, 11.2 kgcm², forced cooling, with holding brake |
AM8552-wKyA | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 8.50 A, nn= 4000 min-1, 10.6 kgcm², forced cooling |
AM8552-wKyB | Servomotor, 400 V AC, Mo= 10.7 Nm, Io= 8.50 A, nn= 4000 min-1, 11.2 kgcm², forced cooling, with holding brake |
AM8552-wNyA | Servomotor, 400 V AC, Mo= 9.6 Nm, Io= 13.6 A, nn= 6000 min-1, 10.6 kgcm², forced cooling |
AM8552-wNyB | Servomotor, 400 V AC, Mo= 9.6 Nm, Io= 13.6 A, nn= 6000 min-1, 11.2 kgcm², forced cooling, with holding brake |
AM8553-wJyA | Servomotor, 400 V AC, Mo= 15.4 Nm, Io= 6.40 A, nn= 2000 min-1, 12.5 kgcm², forced cooling |
AM8553-wLyA | Servomotor, 400 V AC, Mo= 15.4 Nm, Io= 11.9 A, nn= 4000 min-1, 12.5 kgcm², forced cooling |
AM8553-wPyA | Servomotor, 400 V AC, Mo= 13.3 Nm, Io= 18.6 A, nn= 5000 min-1, 12.5 kgcm², forced cooling |
AM8561-wHyA | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 5.20 A, nn= 1400 min-1, 48.2 kgcm², forced cooling |
AM8561-wHyB | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 5.20 A, nn= 1400 min-1, 50.6 kgcm², forced cooling, with holding brake |
AM8561-wLyA | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 10.1 A, nn= 3000 min-1, 48.2 kgcm², forced cooling |
AM8561-wLyB | Servomotor, 400 V AC, Mo= 17.1 Nm, Io= 10.1 A, nn= 3000 min-1, 50.6 kgcm², forced cooling, with holding brake |
AM8561-wNyA | Servomotor, 400 V AC, Mo= 15.5 Nm, Io= 15.8 A, nn= 5000 min-1, 48.2 kgcm², forced cooling |
AM8561-wNyB | Servomotor, 400 V AC, Mo= 15.5 Nm, Io= 15.8 A, nn= 5000 min-1, 50.6 kgcm², forced cooling, with holding brake |
AM8562-wKyA | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 8.70 A, nn= 1400 min-1, 57.1 kgcm², forced cooling |
AM8562-wKyB | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 8.70 A, nn= 1400 min-1, 59.6 kgcm², forced cooling, with holding brake |
AM8562-wNyA | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 17.4 A, nn= 3000 min-1, 57.1 kgcm², forced cooling |
AM8562-wNyB | Servomotor, 400 V AC, Mo= 29.9 Nm, Io= 17.4 A, nn= 3000 min-1, 59.6 kgcm², forced cooling, with holding brake |
AM8562-wRyA | Servomotor, 400 V AC, Mo= 28.1 Nm, Io= 28.7 A, nn= 5000 min-1, 57.1 kgcm², forced cooling |
AM8562-wRyB | Servomotor, 400 V AC, Mo= 28.1 Nm, Io= 28.7 A, nn= 5000 min-1, 59.6 kgcm², forced cooling, with holding brake |
AM8563-wLyA | Servomotor, 400 V AC, Mo= 41.4 Nm, Io= 11.6 A, nn= 1400 min-1, 66.1 kgcm², forced cooling |
AM8563-wQyA | Servomotor, 400 V AC, Mo= 41.4 Nm, Io= 24.0 A, nn= 3000 min-1, 66.1 kgcm², forced cooling |
AM8563-wTyA | Servomotor, 400 V AC, Mo= 40.1 Nm, Io= 39.8 A, nn= 4000 min-1, 66.1 kgcm², forced cooling |
d. XTS
AX8620-1000 | Power supply module 20 A for supply voltage 100…240 V AC |
AX8620-0000 | Power supply module 20 A for supply voltage 400…480 V AC |
AX8640-1000 | Power supply module 40 A for supply voltage 200…240 V AC |
AX8640-0000 | Power supply module 40 A for supply voltage 400…480 V AC |
AX8108-0000 | Single-axis module 8 A, OCT feedback, without TwinSAFE |
AX8108-0100 | Single-axis module 8 A, feedback: OCT, TwinSAFE: STO/SS1, TwinSAFE Logic integrated |
AX8108-0200 | Single-axis module 8 A, feedback: OCT, TwinSAFE: Safe Motion, TwinSAFE Logic integrated |
AX8118-0000 | Single-axis module 18 A, OCT feedback, without TwinSAFE |
AX8118-0100 | Single-axis module 18 A, feedback: OCT, TwinSAFE: STO/SS1, TwinSafe Logic integrated |
AX8118-0200 | Single-axis module 18 A, feedback: OCT, TwinSAFE: Safe Motion, TwinSafe Logic integrated |
AX8206-0000 | Double-axis module 2 x 6 A, OCT feedback, without TwinSAFE |
AX8206-0100 | Double-axis module 2 x 6 A, feedback: OCT, TwinSAFE: STO/SS1, TwinSafe Logic integrated |
AX8206-0200 | Double-axis module 2 x 6 A, feedback: OCT, TwinSAFE: Safe Motion, TwinSafe Logic integrated |
AX8810-1000 | Capacitor module/DC-Link extension module 4420 µF, 100…240 V AC |
AX8810-0000 | Capacitor module/DC-Link extension module 1755 µF, 400…480 V AC |
ZS4800-2013 | connector for AX8000: X13/X23 motor connector plug, plug 8-pin, max. 6.0 mm² (power), max. 1.5 mm² (OCT/thermo+brake) |
4. Automation
a. TwinCAT 3
Product | Description |
TE1000 | TC3 Engineering |
TE1111 | TC3 EtherCAT Simulation |
TE1120 | TC3 XCAD Interface |
TE1200 | TC3 PLC Static Analysis |
TE1210 | TC3 PLC Profiler |
TE1300 | TC3 Scope View Professional |
TE1310 | TC3 Filter Designer |
TE1400 | TC3 Target for MATLAB®/Simulink® |
TE1410 | TC3 Interface for MATLAB®/Simulink® |
TE1420 | TC3 Target for FMI |
TE1500 | TC3 Valve Diagram Editor |
TE1510 | TC3 Cam Design Tool |
TE1610 | TC3 EAP Configurator |
TE2000 | TC3 HMI Engineering |
TE35xx | TC3 Analytics Workbench |
TC1000-0020 | TC3 ADS, platform 20 (Economy) |
TC1000-0030 | TC3 ADS, platform 30 (Economy Plus) |
TC1000-0040 | TC3 ADS, platform 40 (Performance) |
TC1000-0050 | TC3 ADS, platform 50 (Performance Plus) |
TC1000-0060 | TC3 ADS, platform 60 (Mid Performance) |
TC1000-0070 | TC3 ADS, platform 70 (High Performance) |
TC1000-0080 | TC3 ADS, platform 80 (Very High Performance) |
TC1000-0081 | TC3 ADS, platform 81 (Many-core 5…8 cores) |
TC1000-0082 | TC3 ADS, platform 82 (Many-core 9…16 cores) |
TC1000-0083 | TC3 ADS, platform 83 (Many-core 17…32 cores) |
TC1000-0084 | TC3 ADS, platform 84 (Many-core 33…64 cores) |
TC1000-0090 | TC3 ADS, platform 90 (Other) |
TC1000-0091 | TC3 ADS, platform 91 (Other 5…8 cores) |
TC1000-0092 | TC3 ADS, platform 92 (Other 9…16 cores) |
TC1000-0093 | TC3 ADS, platform 93 (Other 17…32 cores) |
TC1000-0094 | TC3 ADS, platform 94 (Other 33…64 cores) |
TC1100-0020 | TC3 I/O, platform 20 (Economy) |
TC1100-0030 | TC3 I/O, platform 30 (Economy Plus) |
TC1100-0040 | TC3 I/O, platform 40 (Performance) |
TC1100-0050 | TC3 I/O, platform 50 (Performance Plus) |
TC1100-0060 | TC3 I/O, platform 60 (Mid Performance) |
TC1100-0070 | TC3 I/O, platform 70 (High Performance) |
TC1100-0080 | TC3 I/O, platform 80 (Very High Performance) |
TC1100-0081 | TC3 I/O, platform 81 (Many-core 5…8 cores) |
TC1100-0082 | TC3 I/O, platform 82 (Many-core 9…16 cores) |
TC1100-0083 | TC3 I/O, platform 83 (Many-core 17…32 cores) |
TC1100-0084 | TC3 I/O, platform 84 (Many-core 33…64 cores) |
TC1100-0090 | TC3 I/O, platform 90 (Other) |
TC1100-0091 | TC3 I/O, platform 91 (Other 5…8 cores) |
TC1100-0092 | TC3 I/O, platform 92 (Other 9…16 cores) |
TC1100-0093 | TC3 I/O, platform 93 (Other 17…32 cores) |
TC1100-0094 | TC3 I/O, platform 94 (Other 33…64 cores) |
TC1200-0020 | TC3 PLC, platform 20 (Economy) |
TC1200-0030 | TC3 PLC, platform 30 (Economy Plus) |
TC1200-0040 | TC3 PLC, platform 40 (Performance) |
TC1200-0050 | TC3 PLC, platform 50 (Performance Plus) |
TC1200-0060 | TC3 PLC, platform 60 (Mid Performance) |
TC1200-0070 | TC3 PLC, platform 70 (High Performance) |
TC1200-0080 | TC3 PLC, platform 80 (Very High Performance) |
TC1200-0081 | TC3 PLC, platform 81 (Many-core 5…8 cores) |
TC1200-0082 | TC3 PLC, platform 82 (Many-core 9…16 cores) |
TC1200-0083 | TC3 PLC, platform 83 (Many-core 17…32 cores) |
TC1200-0084 | TC3 PLC, platform 84 (Many-core 33…64 cores) |
TC1200-0090 | TC3 PLC, platform 90 (Other) |
TC1200-0091 | TC3 PLC, platform 91 (Other 5…8 cores) |
TC1200-0092 | TC3 PLC, platform 92 (Other 9…16 cores) |
TC1200-0093 | TC3 PLC, platform 93 (Other 17…32 cores) |
TC1200-0094 | TC3 PLC, platform 94 (Other 33…64 cores) |
TC1210-0040 | TC3 PLC/C++, platform 40 (Performance) |
TC1210-0050 | TC3 PLC/C++, platform 50 (Performance Plus) |
TC1210-0060 | TC3 PLC/C++, platform 60 (Mid Performance) |
TC1210-0070 | TC3 PLC/C++, platform 70 (High Performance) |
TC1210-0080 | TC3 PLC/C++, platform 80 (Very High Performance) |
TC1210-0081 | TC3 PLC/C++, platform 81 (Many-core 5…8 cores) |
TC1210-0082 | TC3 PLC/C++, platform 82 (Many-core 9…16 cores) |
TC1210-0083 | TC3 PLC/C++, platform 83 (Many-core 17…32 cores) |
TC1210-0084 | TC3 PLC/C++, platform 84 (Many-core 33…64 cores) |
TC1210-0090 | TC3 PLC/C++, platform 90 (Other) |
TC1210-0091 | TC3 PLC/C++, platform 91 (Other 5…8 cores) |
TC1210-0092 | TC3 PLC/C++, platform 92 (Other 9…16 cores) |
TC1210-0093 | TC3 PLC/C++, platform 93 (Other 17…32 cores) |
TC1210-0094 | TC3 PLC/C++, platform 94 (Other 33…64 cores) |
TC1220-0040 | TC3 PLC/C++/Matlab®/Simulink®, platform 40 (Performance) |
TC1220-0050 | TC3 PLC/C++/Matlab®/Simulink®, platform 50 (Performance Plus) |
TC1220-0060 | TC3 PLC/C++/Matlab®/Simulink®, platform 60 (Mid Performance) |
TC1220-0070 | TC3 PLC/C++/Matlab®/Simulink®, platform 70 (High Performance) |
TC1220-0080 | TC3 PLC/C++/Matlab®/Simulink®, platform 80 (Very High Performance) |
TC1220-0081 | TC3 PLC/C++/Matlab®/Simulink®, platform 81 (Many-core 5…8 cores) |
TC1220-0082 | TC3 PLC/C++/Matlab®/Simulink®, platform 82 (Many-core 9…16 cores) |
TC1220-0083 | TC3 PLC/C++/Matlab®/Simulink®, platform 83 (Many-core 17…32 cores) |
TC1220-0084 | TC3 PLC/C++/Matlab®/Simulink®, platform 84 (Many-core 33…64 cores) |
TC1220-0090 | TC3 PLC/C++/Matlab®/Simulink®, platform 90 (Other) |
TC1220-0091 | TC3 PLC/C++/Matlab®/Simulink®, platform 91 (Other 5…8 cores) |
TC1220-0092 | TC3 PLC/C++/Matlab®/Simulink®, platform 92 (Other 9…16 cores) |
TC1220-0093 | TC3 PLC/C++/Matlab®/Simulink®, platform 93 (Other 17…32 cores) |
TC1220-0094 | TC3 PLC/C++/Matlab®/Simulink®, platform 94 (Other 33…64 cores) |
TC1250-0030 | TC3 PLC/NC PTP 10 axes, platform 30 (Economy Plus) |
TC1250-0040 | TC3 PLC/NC PTP 10 axes, platform 40 (Performance) |
TC1250-0050 | TC3 PLC/NC PTP 10 axes, platform 50 (Performance Plus) |
TC1250-0060 | TC3 PLC/NC PTP 10 axes, platform 60 (Mid Performance) |
TC1250-0070 | TC3 PLC/NC PTP 10 axes, platform 70 (High Performance) |
TC1250-0080 | TC3 PLC/NC PTP 10 axes, platform 80 (Very High Performance) |
TC1250-0081 | TC3 PLC/NC PTP 10 axes, platform 81 (Many-core 5…8 cores) |
TC1250-0082 | TC3 PLC/NC PTP 10 axes, platform 82 (Many-core 9…16 cores) |
TC1250-0083 | TC3 PLC/NC PTP 10 axes, platform 83 (Many-core 17…32 cores) |
b. TwinCAT 2
TR8010 |
TwinCAT 2 Training: TwinSAFE |
TR8011 |
TwinCAT 2 Training: TwinSAFE AX5805 option card |
TR8016 |
TwinCAT 2 Training: TwinSAFE training – Maintenance and servicing |
TR8020 |
TwinCAT 2 Training: EtherCAT |
c. TwinSAFE
AX5805-0000 | TwinSAFE drive option card for AX5000 up to 40 A, HW 2.0: Safe Motion |
AX5806-0000 | TwinSAFE drive option card for AX5000 from 60 A HW 2.0: Safe Motion |
AX5801-0000 | TwinSAFE drive option card for AX5000 up to 40 A, HW 1.0: STO/SS1 |
AX5801-0200 | TwinSAFE drive option card for AX5000 up to 40 A, HW 2.0: STO/SS1 |
