GEAR PUMPS H-Series LIQUIFLO

H-SERIES MODEL

H1F

H3F

H5R

H5F

H7N

H7R

H7F

H9R

H9F

H12R

H12F

H14F

Port Connections:
  NPT/BSPT
  ANSI 150# RF FLG
  DIN PN16 RF FLG

in
in
mm

1/4
1/2
10

1/4
1/2
10

1/2
1/2
15

1/2
1/2
15

3/4
3/4
20

3/4
3/4
20

3/4
3/4
20

1
1
25

1 ¼
1 ¼
32

1 ¼
1 ½
40

1 ¼
1 ½
40

-
2 ½
65

Max Flow Rate

GPM

0.5

1.4

2.4

3.4

5.4

8.6

10.7

15

21.5

22

29

58

Max Differential
Pressure

PSI

225

225

225

225

225

225

225

225

225

225

225

225

Max Discharge
Pressure

PSIG

300

300

300

300

225

225

225

225

225

270

270

270

Max Temperature

°F

500

500

500

500

500

500

500

500

500

500

500

500

Min Temperature

°F

-40

-40

-40

-40

-40

-40

-40

-40

-40

-40

-40

-40

Max Speed

RPM

1750

1750

1750

1750

1750

1750

1750

1750

1750

1150

1150

1150

NPSHR @ Max Speed

ft (a)

3

2

2

2

5.2

5.2

5.2

4

3

5

5

3

Weight (less motor)

  Sealed, Long-Coupled
  Sealed, Close-Coupled
  Mag, Close-Coupled
  Mag, Long-Coupled

lbs

2.5
23
31
-

2.5
23
31
-

3.5
24
32
-

3.5
24
32
-

6.5
29
36
-

6.5
29
36
-

6.5
29
36
-

8
34
38
-

10
36
40
-

52
77
79
70

52
77
79
70

67
95
95
-
