MDR 3000 MONTECH MÁY ĐO LƯU LƯỢNG KẾ DI CHUYỂN NÂNG CAO MONTECH

International standards

ISO 6502, ASTM D 5289, DIN 53529

Die configuration

Biconical, closed die system, sealed

Drive system

Direct, wearless servo drive system

Oscillation frequency

1.667 Hz

Oscillation strain

+/- 0.01° to 5° Programmable via Software

Temperature range

Ambient to 232 °C

Measured Data

Torque, temperature, frequency, strain Optional: Normal force

Calculated Data

S΄, S˝, S*, tan δ

Die gap

0.45 mm nominal

Sample volume

approx. 4.5 cm³

Drive system

Direct, wearless servo drive system

Closing system

Soft closing to prevent foil rips and damage of test sample

Torque range

Torque range

Temperature control system

Ambient to 232 °C, precision +/- 0.03 °C, Max. heating rate: 85°C/min, digital, microprocessor controlled

Temperature check system

Recordings of the temperature gradient on the screen, microprocessor monitored

Data Interface

Ethernet (10/100 MBit), USB (int.), CF card (int.), RS232 (opt.)

Data points

Over 3500 data points available for each test; Including S‘ Min, S‘ Max, TS 1, TS 2, TC 10, TC 30, TC 50, TC 90

Pneumatics

min. 4.5 Bar / 60 psi

Electrical

200 V - 240 V, 6 Amps, 50/60Hz

Instrument options

“M” version with mechanical drive system; Instrument control panel with 5“ touchscreen display and printer; Normal force / Pressure measurement; Double channel forced air cooling system; Autoloader 5 or 10 sample linear; Autoloader with 24, 48 or 100 sample tray or tray changers; R-VS 3000 constant volume sample cutter
