Specifications

Accuracy:

Thermistor temperature sensor: ±0.22°C @ 25°C (±0.4°F @ 77°F); RTD temperature sensor DIN Class A: ±0.15°C @ 0°C (±0.28°F @ 32°F).

Temperature Limits:

Operating: -40 to 302°F (-40 to 150°C).

Sensor Curves:

See Resistance vs. Temperature Table.

Cable Rating:

Plenum option includes UL listed plenum cable.

Housing Material:

Meets UL, 94 V-O polycarbonate plastic.

Thermowell Material:

TE-I: 304 SS.

Housing Rating:

NEMA 4X (IP66) (DFW, IBW only).

Weight:

5.3 oz (150.3 g).

Agency Approvals:

Meets the technical requirements of EU Directive 2011/65/EU (RoHS II).
