Specifications

Service:

Compatible liquids and combustible gases (for FM listing see Agency Approvals below).

Wetted Materials:

Type 316L SS.

Housing Materials:

Polycarbonate front and back cover, anodized aluminum extruded housing with recessed grooves, polycarbonate overlay, Buna-N O-rings, 316L SS sensor construction.

Accuracy:

DPG-000: 0.5% FS; DPG-100: ±0.25% FS; ±1 least significant digit @ 70°F (21°C) (includes linearity, hysteresis, repeatability).

Pressure Limit:

2x pressure range for models ≤1000 psi; 5000 psi for 3000 psi range; 7500 psi for 5000 psi range.

Enclosure Rating:

Designed to meet NEMA 4/4X (IP66).

Temperature Limits:

0 to 130°F (-18 to 55°C).

Thermal Effect:

Between 70 to 130°F is 0.016%/F. Between 32 to 70°F is 0.026%/F. Between 10 to 32°F is 0.09%/F. Between 0 to 10°F is 0.50%/F.

Size:

3.00" OD x 1.90" deep (max).

Process Connection:

1/4" male NPT.

Weight:

8.84 oz (275 g).

Display:

4 digit (.425" H x .234" W digits).

Power Requirements:

(2) AAA alkaline batteries, included, user replaceable.

Battery Life:

2000 hours typical; Low battery indicator. (60 hours in continuous use).

Auto Shut-Off:

Gage: 60 minute auto shut-off. Auto shut-off may be disengaged. Backlight: 2 minute auto shut-off.

Agency Approvals:

DPG-000: CE; DPG-100: CE, FM approved to be intrinsically safe for Class I, Division 1, Groups A, B, C and D, for ranges 0-5 to 0-3000 psi.
