CẢM BIẾN RUNG TR-26 CEMB- CEMB VIET NAM
HÃNG:

CEMB

XUẤT XỨ:

Italy

GIÁ BÁN:

LH: 0901.251.739

THÀNH PHẦN:

Mới 100% - Chính hãng

MÃ SẢN PHẨM:

TR-26

The integrated transmitter TR-26 measures the absolute vibrations of any rotating machine support

TR-26 monitors vibration of the point where fixed and interfaces directly to PLC/DCS 2 wires current loop.

Công Ty Tăng Minh Phát chuyên cung cấp thiết bị của hãng CEMB tại Việt Nam,
Tags: TR-26 CEMB ĐẠI LÝ CEMB VIETNAM CẢM BIẾN RUNG TR-26

Thông Tin Sản Phẩm
Đánh Giá

TR-26

Absolute vibration transmitter :

The integrated transmitter TR-26 measures the absolute vibrations of any rotating machine support

The transmitter, secured directly on machinery, generates an electric signal (4÷20 mA) which is proportional respectively to vibration velocity or acceleration.

The transmitter is made of an AISI 316L body with machine connection thread; the connection to the acquisition system is effected by means of a MIL-C-5015-2 poles connector.

NOTE: The transmitter is available in different configuration versions and does not need any set-up or maintenance.

TR-26 monitors vibration of the point where fixed and interfaces directly to PLC/DCS 2 wires current loop. It is available with different certifications

THÔNG SỐ KỸ THUẬT TR-26:

Vibration trasmitter Cemb TR-26
Power supply	24 Vdc (10 ÷ 35 Vdc) current loop 4 ÷ 20 mA (2 wires)
External connections	MIL-C-5015 2 poles connector (conductors max section 2,5 mm²)
	4 poles M12 connector
Environmental	- 60°C ÷ + 120°C
	IP 65 EN 60529/10.91 standards
Measure type	Omnidirectional seismic (absolute vibration)
Dynamic field	± 18 g
Transverse sensitivity	< 5 %
Linearity	± 2% - 75 Hz
Dynamic performances	±3% / 10Hz – 1kHz - see Figure 2
	-3db / 1.5Hz – 2.5kHz
Insulation	≥108 Ω between signal and container
Application axis	Any
Standard machine connection thread	M8x1,25
	¼”-18NPT
	¼’’-28UNF
	M6x1
Maintenance	No maintenance is needed
Electrical connections	Bipolar shielded cable, conductors typical section 2x1mm²
Parameters to be defined when ordering	Measuring field - Machine connection thread - Certification - Connection
Mounting torque	5÷10 N-m
Certification available	Ex II 2 G Ex ia IIC T6, T5, T4 Gb (ATEX) - Ex ia IIC T6, T5, T4 Gb (IECEx)
